Cnc Flat Bed Lathe Machine Ck6140d - 2300x1350x1700mm, 400mm Max Swing, 25-1600rpm Spindle Speed, Mt6 Taper, 1700kg Weight, Cnc Controlled, High Precision, Durable Design

DESCRIPTION OF GOODS

THE CNC system is GSK980TDC, With both horizontal and vertical structure. With 8.4-inch color LCD,

can control the five feed axis (including Cs axis), 2 analog spindle, the minimum unit of 0.1m. and also

can be make in Chinese, English, Spanish, Russian, Portuguese and other languages for different country customers.
Xaxis and Z axis are controlled by the semi-closed loop. It is drived by the servo motor to drive the precision

ball leadscrew to achieve fast shifting and rapid feeding.Ballscrew is C3 degree with high precision.
All electric part all passed CE approve.
The machine with 4 position too post which brand is very famour in China,high positioning accuracy,

high strength, good shock resistance.
Before machine leave factory,we have to pass stric inspection.every machine all test the positioning

accuracy and repeatability accuracy of X AXIS and Z AXIS by laser interferometer to ensure machines precision.
Machine adopts Centralized lubrication of famous brand HERGfrom Japan.headstock lubrication

adopts Taiwan Po Teng cycloid pump forced circulation lubrication
The bed adopts Resin sand molding, high-quality cast iron casting, width of bed 312mm, guide way

fired depth is up to 3mm, improving wear resistance and stability
Spindle structure using front and rear ends of the typical structure of two points of support, with high rigidity.
Main drive for the second gear stepless frequency control, speed range of 21 ~ 1600r / min
The design of headstock fully consider the cooling measures and shock absorption mechanism, making

headstock with low noise, high precision transmission characteristics.
