Cnc Controllers - 5 Axis Control, 6m/min Max Speed | 0.001mm Resolution, Multi-function Drilling, Usb Interface, Multi-language Support

Being a customer oriented organization, we are highly engaged in offering a wide range of CNC Controllers to the clients from Delhi. We are actively involved in manufacturer and supplier huge range of this product which is provided at very reasonable price in the market.

Product Features:
The five axis of X, Z, Y, 4th and 5th control, any three axis linkage movement, the axial name and the axial type of 4th and 5th can be defined.
2ms interpolation cycle.
Maximum speed: 6m/min
0.001mm, or 0.0001inch resolution
Multiple functions, it can perform the drilling/boring, roughing of round groove/rectangle groove, finishing of full circle/rectangle, continuous drilling of straight line/rectangle/arc, etc.
Bui lt-in many PLC programs, current running PLC programs can be selected.
Memory capacity: 40M, total 10,000 part programs.
Support macro command programming in sentence type and the calling of macro program with the Parameter.
Support metric system/inch system, with the function of auto chamfering and tool life management.
Display in Chinese, English, Spanish, and Russian, which can be selected by the parameter.
With USB interface, support USB file processing, system configuration and software upgrade.
DNC in high speed, realize part program real-time transmission processing.
Analog voltage output of 0V-10V in two channels, support two-spindle control.
One channel for remote jogging, supporting external/internal MPG.
Common I/O in 40 inputs, 32 outputs.
