Climatic Chambers - 32"x36"x60" Dimensions, -20â°c To 100â°c Temp Range, 95% Humidity, Stainless Steel, Reliable, Precise Control, Easy Use

Climatic Chambers - 32"x36"x60" Dimensions, -20â°c To 100â°c Temp Range, 95% Humidity, Stainless Steel, Reliable, Precise Control, Easy Use

Price:

Get Latest Price

In Stock

In Stock

Product Specifications

Work Space24X24X24
Temperature Range-20C To 100C
Temperature Tolerance+/- 1C
Humidity Range95% +/- 3%
Power440V
ConstructionDouble Wall
Overall Dimensions32X36X60
FeaturesPrecise Control, Wide Range, Uniformity, Reliable, Durable, Easy Use

Product Overview

Key Features


Climatic Chambers

Specification For Climatic Chambers
01.
Work - Space

: 24 "(L)x 24"(D) x 24"(H)

02.
Temperature range
: - 20o C to 100o C
03.
Temperature tolerance
: + / - 1 o C
04.
Humidity Range
: 95% +/- 3% temp. range 25o C to 60o C
05.
Temperature control
By solid state digital temperature Indicator Controller for dry and wet bulb with PT-100
05.
Power
440 V + / - 5%, 3 phase neutral 50 Hz at 15 amp/phase stabilized AC supply
06.
Construction
Double wall type with


Interior

Exterior

Insulation

Door

Gasket

Hinges and Latches

Mounting
: 22 swg Stainless Steel
: 20 Swg CRCA MS sheets with powder coating

: 1 00 mm glass wool insulation

: Full front opening door double walled insulated and interior lined with stainless steel

: Double gasket one on chamber and one on the door

: Heavy duty hinges with locking system

: Trolley mounting type with castors
07.
Overall dimensions
: 32 " (L) x 36" (D) x 60 " (H)

Systems Provided

Air-Circulation system

1/8 Hp capacity continuous rated 230 Volts, single phase AC operated motor along with 7 " dia impeller has been provided for uniform temperature and humidity condition inside the chamber.

Humidity system

Low surface loading inconel tube heaters having capacity 500 watts-2nos. Has been provided to add heat inside the chamber. All the heaters are mounted in the conditioning space and will operate in the black zone.

Humidity system

Low pressure moisture generator tank has been provided to generate the moisture and add humidity in the chamber. 2 KW capacity immersion heater having 1 V4 BSP threading has been provided inside the moisture generator tank. The moisture generator tank has been provided along with low water level controller with mechanical float type refilling arrangement .

Control panel and wiring

Separate control panel provided on the top of the chamber which I ncorporate all the indicating and monitoring instruments with control switches, MCB"S , contactors, indicating lamps etc. All the wiring will be done as per IS color code with channel type wiring.

Utilities provided

a. Chamber drain
b. Viewing window 30x30 cms 2 pane glass with low wattage heater and manually operated wiper.
c. Chamber interior light.
d. Port hole 25mm dia 1 no.
e. Terminal Panel - 6 nos. 5 amps capacity
f. 30 Lts. capacity S/S tank provided on the top for water storage.

Water requirement

30 Lts/day dematerialized water during the humidity test.
