Ceramic Capacitors 50v - 100v

Ceramic Disc Capacitors 50v~100V








CC series (Class l: 50V~100V)








Operating temperature range:
 -25 to 85 C


Capacitance tolerance:
 0.5 to 10pF: 0.25pF, above10pF: +/- 5%, +/- 10% above


Rated voltage:
50,100VDC


Test voltage:
3 times rate voltage for 1.5 seconds


Insulation resistance:
10,000M ohm minimum at WVDC 60 seconds








CC series (Class ll: 50V~100V)








Operating temperature range:
Y5E: Temp range: -25 to +85C: Cap change: +/- 4.7%




Y5P: Temp range: -25 to +85 C: Cap change: +/-10%




Z5U: Temp range: -10 to +85 C: Cap change: +22 to -56%




Z5V: Temp range: -10 to +85 C: Cap change: +22 to -82%


Min Capacitance Tolerance
Y5P: +/- 10%, Z5U: +/- 20%, Z5V: +80 to -20%




(within tolerance at 1 KHz and 25 degrees Celsius )


Rated voltage:
50,100VDC


Test voltage:
3 times rated voltage for 1.5 seconds


Insulation resistance:
10,000M ohm minimum at WVDC


Dissipation factor:
2.5% maximum for Y5E, Y5P at 1KHz and 25 degrees Celsius




3.5% maximum for Z5U, Z5V at 1KHz and 25 degrees Celsius


Life test:
 1.5 time working voltage at 85 degrees Celsius for 500 hours
