Cbl04a Aviation Light Control Box - Die Casting Aluminum, 18-65v Dc, 110-240v Ac | Multi-light Control, Alarm Signal For Light Failure, External Photocell Integration

Being one of the trusted organizations in the market, we are engaged in exporting and supplying an excellent quality collection of CBL04A Aviation Light Control Box in Shanghai, China. CBL04A Control Box employs MCU IC control technology. With a pre-programmed software, CBL04A can control up to 4 aviation obstruction lights. When any light fail, the control box will send a alarm signal to alarm device in BTS in order for maintaneance staff to replace the light immediately. if needed, it can turn on all light in the system and make them flash at the same time. (Control box that can control more than 4 lights are also available upon request).
A photocell is included with the control box, which can turn on/off the system at dawn/dusk. The photocell should be installed in open environment.
CBL04A added a extra surge protection than CBL04. The surge protector can risist up to 65KA, 2.2KV
A
Functions Features:
-ControlA severalA lightsA flashingA synchronously
-Led indicator, in case of light failure, the control panel will give an alarm, at the same time, ledA indicatorA will show.
-The alarm signal is relay contact, inactive.
-A With override manual switch-can switch ON/OFF the lig ht when the photocell is not available
-A With external photocell, in case of photocell failure, the control will give an alarm
