Cast Iron Reducer Door Tee

Name: Cast Iron Reducer Door Tee
Price: 250 INR
Availability: InStock

Price: 250 INR

Get Latest Price

In Stock

Product Specifications

Access Door	Optional
Branches	Unequal
Color	Red
Diameter Range	50-150 mm
Features	High strength, Corrosion resistant, Durable design, Customizable sizes, Easy installation
Material	Cast Iron
Usage	Plumbing and drainage systems; connects pipes of different diameters.
Weight Range	3.1-13.1 kg

Product Overview

Key Features

From our wide range of products, we are offering our clients a supreme grade variety of Cast Iron Reducer Door Tee. Owing to its corrosion resistance, optimum finish, high strength and durability, this product is widely appreciated and highly demanded among our clients. The offered product is quality tested under the guidance of our expert quality controllers. Cast Iron Reducer Door Tee is offered in a range of dimensions that can be modified, as per the requirements of our clients.

Specifications:

Unequal Branches with and without Access Door

Angle o	Nominal Diameter		Dimensions				Approximate mass of single branch		Approximate mass of Double branch
	Body	Branch Pipe	e	1	A	b	Plain (kg)	With Door (kg)	Plain (kg)	With Door (kg)
	DN	dn	e	1	A	b	Plain (kg)	With Door (kg)	Plain (kg)	With Door (kg)
92.5^o	75	50	3.5	181	39	51	3.1	3.5	3.8	4.2
	100	50	3.5	190	40	63	4.2	4.8	4.5	5.4
	100	75	4.0	211	52	65	4.9	5.5	6.0	6.6
	150	100	5.0	242	67	92	9.1	9.9	10.5	11.3
135^o	75	50	3.5	197	101	106	3.3	3.7	4.0	4.4
	100	50	3.5	210	115	125	4.3	4.9	5.2	5.8
	100	75	4.0	239	133	139	5.5	6.1	6.4	7.0
	150	100	5.0	283	176	190	10.6	11.4	12.3	13.1
