Cable Route Tracer - High Voltage Surge Generator Up To 16kvdc | Compact Design, Built-in Icm & Arc Reflection Filter, Effective For Fault Location And Cable Testing

We are engaged in offering , which is appreciated by our client for its best quality of HT Cable Route Tracer SET T-1016, T-1016(5RL), T-1020, T-1020(8RL), T-1032, T-1032(10RL), T-1032(15RL).
Features:


Suitable for fault location in medium high voltage cables.
High voltage testing up to 16 KVDC.
Limited Burning Capability.
500J Energy on 4, 8, 16 KV Range.
Built in ICM & Decay Coupler for Reflectometer T-510.
Built in ARC Reflection Filter.
Suitable as thumper required for pinpointing of fault.
Compact design.
Suitable to operate on mains (220-230/240 VAC, 45Hz up to 60 Hz) or portable generator.

Description

Instrument has been primarily designed to produce high voltage surges for pre-location of under ground cable fault in combination with Reflectometer T-510.
The surges produced help in pinpointing the fault and tracing the route of the cable when used with acousticDIGIPOINT surge generator generates D.C. high voltage for pressure testing of the underground cables to find out faulty phase and the breakdown voltage with leakage current.
It can also be used as effective burn down instrument with 200mA current on 4KV range.

Output Voltage Range Short Circuit Current
I 0- 4 KV. 200 mA.
II 0- 8 KV. 100 mA.
III 0- 16 KV. 50 mA.
Maximum Surge Energy 500 JOULES on each range.
