Butterfly Valves Pneumatically Actuated

Price:

Get Latest Price

In Stock

Product Overview

Key Features

We manufacture the best quality Butterfly Valves Pneumatically Actuated, which are broadly used in chemical industries. This Butterfly Valves Pneumatically Actuated controls the flow of fluid. These are available in various shapes, sizes and dimensions as per requirements of the clients. This is highly durable, fine finish and has longer functional life. These valves are manufactured with high grade raw materials that are procured from the best vendors of the in industry.

Dimension Table

Size (NB)	D1	D2	D3	e	n	L	L1	H1	H2
50 MM	51	121	160	19	04	35	42	83	102
65 MM	65	140	182	19	04	30	42	91	108
80 MM	80	152	200	19	04	37	46	100	118
100 MM	100	191	229	18	08	46	54	115	132
125 MM	130	216	250	22	08	57	66	127	160
150 MM	150	241	280	22	08	59	74	140	170
200 MM	200	298	338	22	08	76	88	169	210
250 MM	255	362	396	25	12	96	111	198	233
300 MM	312	432	478	25	12	116	132	239	289
350 MM	358	476	514	28	12	116	132	257	305
400 MM	398	540	594	28	16	153	169	297	353
450 MM	451	578	634	32	16	166	181	317	365
500 MM	500	635	704	32	20	171	190	352	405
600 MM	600	749	805	35	20	191	209	403	460

Material Specification

DESCRIPTION	QTY.	MATERIAL
BODY	1	PP / ISO.PP / PPH / PVDF / UPVC / CPVC
SEAT	1	EPDM / VITON
DISC	1	PP / ISO.PP / PPH / PVDF / UPVC / CPVC
DISC 'O' RING		EPDM / VITON
DISC 'O' RING	1	EPDM / VITON
STEM	1	SS-410/SS-304
STEM 'O' RING	2	EPDM / VITON
PNE. ACTUATOR	2	CAST ALUMINIUM - ANODISED
MOUNTING BRACKET	1	MS EPOXY PAINTED
COUPLER	1	MS EPOXY PAINTED
POSITION INDICATOR	1
FASTENERS	1	SS-304

Notes:

If manual override application & Limit Switch are required height "H' may increase accordingly.
Actuator Size may vary as per Actuator type and Air Supply pressure rating.
Solenoid valve & Coil will be available as per requirement.
Electrically Actuated Ball valves also can be offered on specific requirements.
