Blueboard-lpc1114
Price:
Get Latest Price
In Stock
Product Specifications
| Connectors | USB, debug |
| Crystal | 12MHz, 32kHz |
| Dimensions | 110mm x 110mm |
| Features | Cost-effective, Ready-to-run, Ubiquitous interfaces, ARM Cortex-M0, In-system programming, Versatile I/O |
| MCU | LPC1114 |
| Material | FR-4 |
| Power | DC 6.5V |
| Regulators | +3.3V/500mA, +5V/500mA |
Product Overview
Key Features
These BlueBoard-LPC1114 is a cost effective prototyping solution. It is a ready-to-run development platform with code snippets to demonstrate applications for every feature supported on the board. The Blue Board offers ubiquitous interfaces making it the best board available for the offered price.
The BlueBoard-LPC1114 is a NXP ARM CORTEX-M0 microcontroller, has 32KB of internal flash and 8KB SRAM. The LPC1114 operate at CPU frequencies of up to 50MHz. In-System Programming (ISP) and In-Application Programming (IAP) via on-chip bootloader software. Programmable WatchDog Timer (WDT). 1 x UART,1 x I2C-bus interfaces Fast-mode Plus with a data rate of 1 Mbit/s. 1 x SSP controllers, 8-channel 10-bit ADC, Four general purpose counter/timers with a total of four capture inputs and 13 match outputs. Integrated PMU power on reset and up to 42 general purpose I/O pins. GPIO pins can be used as edge and level sensitive interrupt sources.
Following are the salient features of the board
Dimensions: 110mm X 110mm
Two layer PCB (FR-4 material)
Power: DC 6.5V with power LED On-board linear regulators generate +3.3V/500mA and +5V/500mA from power supply USB connector (as alternate power source)
10 pin, 20 pin CORTEX debug connector for SWD (Serial Wire Debug)
ISP, Wakeup, External Interrupt and reset switch
12.0000 MHz crystal for MCU, 32Khz crystal for RTC
Extension headers for all microcontroller pins
The BlueBoard-LPC1114 is a NXP ARM CORTEX-M0 microcontroller, has 32KB of internal flash and 8KB SRAM. The LPC1114 operate at CPU frequencies of up to 50MHz. In-System Programming (ISP) and In-Application Programming (IAP) via on-chip bootloader software. Programmable WatchDog Timer (WDT). 1 x UART,1 x I2C-bus interfaces Fast-mode Plus with a data rate of 1 Mbit/s. 1 x SSP controllers, 8-channel 10-bit ADC, Four general purpose counter/timers with a total of four capture inputs and 13 match outputs. Integrated PMU power on reset and up to 42 general purpose I/O pins. GPIO pins can be used as edge and level sensitive interrupt sources.
Following are the salient features of the board
Dimensions: 110mm X 110mm
Two layer PCB (FR-4 material)
Power: DC 6.5V with power LED On-board linear regulators generate +3.3V/500mA and +5V/500mA from power supply USB connector (as alternate power source)
10 pin, 20 pin CORTEX debug connector for SWD (Serial Wire Debug)
ISP, Wakeup, External Interrupt and reset switch
12.0000 MHz crystal for MCU, 32Khz crystal for RTC
Extension headers for all microcontroller pins
