Bangle Profiling Machine
Price:
Get Latest Price
In Stock
Product Specifications
| Operating System | Motorized |
| Max Profile Thickness | 14 Gauge |
| Max Bangle Width | 40 Mm |
| Bangle Profiling Diameter | 38 Mm To 76 Mm |
| Max Ring Width | 10 Mm |
| Ring Profiling Diameter | 13 Mm To 37 Mm |
| Roller Speed | 45 Rpm |
| Shaft Motor | 1 Hp (0.75 Kw) 220V Ac |
| Electrical Load | 1.4 Kva |
| Dimensions (Lxwxh) | 52X41X64 Cms |
| Floor Space | 52X41 Cms |
| Net Weight | 108 Kg |
| Gross Weight | 175 Kg |
| Shipping Dimensions | 68X63X83 Cms |
| Features | Precise Profiling Efficient Operation Durable Design Easy Operation Versatile Use High Precision Cost Effective Reliable Machine |
Product Overview
Key Features
Keeping in mind continually progressing specifications of our considerable customers we are Exporting Manufacturing and Supplying a discerning array of Bangle Profiling Machine in Jamnagar Gujarat India. The offered extent is made utilizing high review material and most recent advancement in consistence with global recommendations. Also one can get these items at sensible rates.
Features:
SR.TECHNICAL DATABPM-686
01.OPERATING SYSTEMMOTORIZED
02.MAXIMUM PROFILE THICKNESS14 GAUGE
03.MAXIMUM WIDTH OF BANGLES1.1/2" (40 mm )
04.BANGLE PROFILING DIAMETER"1.1 / 2"" TO 3""
(38 mm TO 76 mm)"
05.MAXIMUM WIDTH OF RING3/8 " (10 mm )
06.RING PROFILING DIAMETER"1/2"" TO 1.15 / 32""
(13 mm TO 37 mm)"
07.ROLLER SPEED45 rpm
08.SHAFT MOTOR SINGLE PHASE1 hp (0.75 kw) 220V AC
09.ELECTRICAL LOAD1.4 KVA
10.DIMENSION ( L X W X H )52 X 41 X 64 cms
11.FLOOR SPACE REQUIRED ( L X W )52 X 41 cms
12.NET WEIGHT WITH STANDARD ACCESSORIES108 kg
13.GROSS WEIGHT WITH STANDARD ACCESSORIES175 kg
14.SHIPPING DIMENSION WITH STANDARD ACCESSORIES ( L X W X H)68 X 63 X 83 cms
Features:
SR.TECHNICAL DATABPM-686
01.OPERATING SYSTEMMOTORIZED
02.MAXIMUM PROFILE THICKNESS14 GAUGE
03.MAXIMUM WIDTH OF BANGLES1.1/2" (40 mm )
04.BANGLE PROFILING DIAMETER"1.1 / 2"" TO 3""
(38 mm TO 76 mm)"
05.MAXIMUM WIDTH OF RING3/8 " (10 mm )
06.RING PROFILING DIAMETER"1/2"" TO 1.15 / 32""
(13 mm TO 37 mm)"
07.ROLLER SPEED45 rpm
08.SHAFT MOTOR SINGLE PHASE1 hp (0.75 kw) 220V AC
09.ELECTRICAL LOAD1.4 KVA
10.DIMENSION ( L X W X H )52 X 41 X 64 cms
11.FLOOR SPACE REQUIRED ( L X W )52 X 41 cms
12.NET WEIGHT WITH STANDARD ACCESSORIES108 kg
13.GROSS WEIGHT WITH STANDARD ACCESSORIES175 kg
14.SHIPPING DIMENSION WITH STANDARD ACCESSORIES ( L X W X H)68 X 63 X 83 cms
