Automatic Side Sealing Strapping System

Our Automatic Side Sealing Strapping System designed by Fromm is the best in the segment in the packaging industry. FROMM Plastic strapping machines are ideal for general palletizing and unitizing and for the well known applications in the corrugated-, can-, bottle-, paper-, and food / beverage industries.

Suitable strapping qualities: Polyester (PET)

Strapping dimensions:
Widths - 13.0 a 32.0 mm
Thicknesses - 0.40 a 1.53 mm
Average seal strength: up to 85% of strap breaking strength
Sealing method: friction welding
Strapping heads*: MH600 MH610
Tension: up to 7000N, adjustable
Tensioning speed: 105 mm/s / 0.34 ft/s
Fully automatic machine is built for the specific requirements of the customer
After sales service is guaranteed by our FROMM subsidiaries and distributors

Optional ::
Pneumatic vertical movement instead of gear motor with chain (if the height of packages changes < 200 mm only)
Device used to detect the end strap and advise on the operator panel
Balancing tension device (for big packages)
Transformer for electric supply different than 400 V / 50/60 Hz
High platform for head maintenance and easy operation
4 lamps: red = emergency stop; white flash light = alarms; orange flash light = end stop;
green = regular operation; green flash light: manual operation
Vertical press up to 400 kg / 880 lbs
Vertical press up to 2000 kg / 4400 lbs
Vertical press up to 5000 kg / 11000 lbs
Automatic top corner protectors
