Automatic High Precision Paper Core Cutting Machine

This CC1500FA core cutter machine is suitable for the production of paper tubes with large batch size and short cutting length,which is suitable for high-volume paper tube cutting. Widely used in textile, stationery, sanitary products, fireworks, plastics,printing, packaging and other industries.

Paper cutting tube machine is widely used in printing, packaging, leather, household, hardware and other industries, especially
suitable for labels, non-woven, film, tape and paper tubes. The tube surface is smooth and flat, no flanging, no burrs.

Features:-
1. Servo motor control to ensure the accuracy of the length of paper tube.
2. Automated online on paper tube and cut off.
3. Product diameter and length can be customized according to customer needs.
4. The machine has reasonable design, operation simple and convenient maintenance.

Specification:-
Cutting length : 1530mm
Power supply by : 3 Phase 380V
Power in : 3KW
Air power in : 0.6-0.8MPA
Core inner size : I 25.6-25.8mm
Cutting length range : 10mm-1530mm
Blade diameter : 80mm
Weight : 300kgs
Machine Dimension : 4540*3103*1769mm
Speed : 2~10seconds/pc (depend on thickness of core)
Knife : Round blade
