Automatic Glass Door Elevator

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Inclination	0 (vertical)
Car Dimension	Customizable (e.g. 1100x1400 mm, as required)
Type	Other, Automatic Glass Door Elevator
Hoist Way Size	Variable as per model
Load Capacity	320-1600 kg
Overhead Height	3500-4200 mm
Pit Depth	1000-1500 mm
Door Opening Size	700-1200 mm (center opening)
Voltage	220V-415V
Usage	Other, Residential, Commercial, Mall, Office, Hotel, Hospital, Showroom
Noise Level	60 dB
Machine Room Size	Standard/Compact/MRL (machine room-less)
Material	other Sheet, Stainless steel + glass panel
Drive Type	Other, Elevator Traction/VVVF Drive
Power Supply	AC 50Hz/60Hz
Speed	0.5 m/s - 1.5 m/s
Max. Lifting Height	Up to 40 meters (variable as per site)
Max. Lifting Weight	Up to 1600 kg
Mechanism Type	Other, Automatic, Electric
Working Temperature	-10C to +50C
Control Device	Other, Microprocessor/PLC-based control
Safety Device	Other, Overload sensor, door interlocks, emergency stop
Capacity	4-20 persons (varies as per design)
Payment Terms	Cash in Advance (CID)
Supply Ability	100 Per Day
Delivery Time	7 Days
Main Domestic Market	All India
