Cyclone Separator

We have marked a distinct position in the market by providing Cyclone Separator. It is manufactured using the best class components procured from reliable vendors in compliance with the set industry norms. The offered gamut of Cyclone Separator is highly acknowledged for its sturdy construction, perfect finish, ability to withstand harsh weather conditions, optimum performance and longer service life. In addition to this, it is available in different specifications to meet the needs of clients.

Description:

• Cyclone separator utilizes centrifugal force generated by a spinning gas stream to separate the particulate matter from the carrier gas
• The centrifugal force on the particles in a spinning gas stream is much greater than gravity
• There is a variety of cyclone designs, differing in manner in which the rotating motion is imparted on the gas stream
• In operation the particle-laden gas upon entering the cyclone cylinder receives a rotating motion
• The vortex so formed develops a centrifugal force, which acts to throw the particles radially towards the wall
• The gas spirals downward to the bottom of the cone and at the bottom the gas flows reverse to form a inner vortex which leaves through the outlet pipe
• In cyclone the gas in addition to moving in a circular path also moves radially
• Since, the tangential velocity of the particles and he gas are same, the relative velocity between gas and particle is simply equal to the radial velocity of gas

This results a drag force on the particle towards the center

Generally the collection efficiency is a function of increasing function of radial velocity

As the diameter of the particle increases or as the cross sectional area of the inlet decreases, radial velocity will increase appreciably, resulting in an increase in efficiency but with a high pressure drop
