Automatic Cementing Toe Lasting Machine For Side And Heel

With years of experience and knowledge in this domain, we are engaged in manufacturing, exporting and supplying a wide range of Automatic Cementing Toe Lasting Machine For Side And Heel. Clients can purchase these products from us at very nominal rates.

1. The quick seventh-sectional switch of this Automatic Shoe Lasting Machine can adjust the cementing path very accurately in different sizes of the shoe.
2. This Shoe Lasting Machine can be simply rotating two screws to regulate the correct cementing path of shoe waist, and it is just one of benefit of quick adjustment features.
3. Lasting Machine also have automatically left and right shoe detection system, auto-detect the right side or left side of the shoe waist to change the cementing path.
4. The cementing distance is according to the laser point setting on the Heel Lasting Machine.
5. Five blocks of finger-press can be controlled independently depending on different sizes of shoe could adjust left and right spacing of pincers, and it could be independently or syn chronically controlled by motor.
6. Pincers could be pull-up automatically, not only equipped the syn chronic adjustment of pressure on right and left pincers, but also the high pressure lifting could be controlled independently pull-up inch by inch.

Product Specifications:-
Automatic Side and Heel Seat Lasting Machine
Model No. TH-668MA
Automatic Cementing: Yes
Motor Power: 2.35KW
Heating Power: 1.50KW
Hydraulic Pressure: 50kg/cmA
Capacity:1300-1600 Pairs
Net Weight: 1045KG
Gross Weight: 1095KG
Voltage: 380V / 220V 50-60HZ
Hydraulic Oil Capacity:90 liters
Machine Size: 1700X1300X1750 mm
Packing Size: 1800x1400x1950mm
Country of Origin:Made in Taiwan
