Aodd Pumps

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Max Suction	Up to 7m (Self-priming dry)
Caliber	Varies (Typically matches Inlet/Outlet size)
Theory	Other, Air Operated Double Diaphragm (AODD)
Discharge Pressure	Up to 7 bar (100 psi)
Speed	Controlled by Air Supply (Variable)
Control System	Manual/Air Logic Controls
Inlet/Outlet	1 to 3 (Flanged or Threaded)
Noise Level	70-90 dB(A)
Frequency	Not Applicable (Pneumatic)
Head Size	Up to 70m
Features	Dry running, Self-priming, Corrosion resistant, ATEX (option), Solids handling
Flow Rate	Up to 1000 LPM (varies by model)
Working Temperature	-10C to 100C (Dependent on material)
Voltage	Not Applicable (Pneumatic Operated)
Mounting Type	Floor/Skid Mounted
Material	Aluminum, Stainless Steel, Polypropylene, PVDF, PTFE
Structure	Other, Double Diaphragm, Air Operated
Power	Other, Compressed Air (No electrical power required)
Standard	ATEX Certified (for hazardous areas, varies by model)
Fuel Type	Other, Compressed Air
Pressure	Other, Maximum 7 bar (100 psi)
Usage	Other, Transfer of Chemicals, Slurries, Solvents, Acids etc.
Application	Other, Chemical Transfer, Food & Beverage, Mining, Paint, Pharmaceutical, Waste Water Treatment
Suction Type	Self-priming/positive suction
Seals Type	Diaphragm (Varies: PTFE, Nitrile, EPDM, Viton etc.)
Priming	Self Priming
Pump Type	Other, AODD (Air Operated Double Diaphragm)
Capacity	Up to 1000 LPM
Payment Terms	Cash in Advance (CID)
Supply Ability	10 Per Month
Delivery Time	5-7 Days
Main Domestic Market	All India
