Vk-bcl Automatic Carton Box Corner Labeling Machine Dimension(l*w*h): 1800x900x1300mm Millimeter (Mm)

VK-BCL is suitable for all kinds of specifications and texture box such as phone box, cosmetic box, food box also can labeling plane products.

VK-BCL can achieve double sealing film labeling, full coverage labeling, partial accurate labeling, vertical multi-label labeling and horizontal multi-label labeling, widely used in cosmetics, electronic, food and packaging materials industries

Voltage specification: AC220V 50/60HZ
Consumed power: 1200W
Labeling speed: 40-70 pieces/min (adjustable speed, depending on object size and label length)
Labeling accuracy: +1mm (depending on product characteristics, hardness and roundness)
Conveyor speed: 50-80 boxes per minute
Scope of object: Length 20-300mm width 50-200mm height 25-300mm
label specification: Width 20mm ~ ~ 130mm length 15 ~ ~ 100mm (special specifications can be customized)
Paper roll diameter: A A paper roll diameter: 76 mm A A 320 (maximum)
Heavy volume: 200KG
Packing size: 1800X900X1300mm

Suit for four kinds corner labeling patterns two top corners, two bottom corners, two diagonal corners. For various specification carton in food, medicine and cosmetics and other industry;

Device characteristics:

Adopt mature technology PLC control system, operation is stable and high-speed;

Using touch-screen control operating system, simple and efficient;

Upgrade new standard station design, the angle can adjust depends on different carton size;

Top press device ensure stability of carton when labeling, particularly applicable for light and small cartons;

Combine the characteristic of light label objects, adopt Belt conveyor with High stability;

Mechanical Design:

The inverter control the Motor, make sure the conveyor speed,press carton speed and send label speed synchronous operation, label surface is smooth and label position is accurate.

The durable engine and parts are solid and durable, adopt standardized modular design completely interchangeable, 24 hours continuous operation ensure the security and stability.

The whole machine use S304 stainless steel and anodized senior aluminum alloy, never rust and with high corrosion resistance.
