Allgeared Radial Drill Machine For Industrial Use

Technical Specifications:
Model 4310 5610 6610
Type of bed Gap bed Gap bed Gap bed
Width of bed 560 mm 655 mm 760 mm
Height of centre 430 mm 560 mm 660 mm
Swing over bed 840 mm 1100 mm 1300 mm
Swing over saddle 600 mm 860 mm 1060 mm
Swing over cross slide 510 mm 770 mm 980 mm
Swing in gap 1250 mm 1510 mm 1710 mm
Length of gap in front of face plate 365 mm 365 mm 365 mm
No. of spindle speed. 8 8 8
Spindle speed range 20 to 275 RPM 20 to 275 RPM 16 to 195 RPM
Spindle hollow 104 mm 104 mm 104 mm
Taper in Tail stock spindle MT a 5 MT a 6 MT a 6
Cross slide travel 430 mm 560 mm 660 mm
Compound slide travel 230 mm 230 mm 300 mm
Tail stock sleeve travel 220 mm 310 mm 410 mm

Bed length/ Admit Beetween Centers(in mm):
4310 5610 6610
Bed length ABC Bed length ABC Bed length ABC
3750 2000 3950 2000 4270 2000
4750 3000 4950 3000 5270 3000
5750 4000 5950 4000 6270 4000
6750 5000 6950 5000 7270 5000
Electric Motor
V Belts
2 MT Centers
Center Bush
Oil Can
Screw Driver
Set of Fixed Spa
