All Geared Radial Drill Machine - Max Drilling Capacity In Steel: 40-65mm, Spindle Travel: 150-300mm, 9 Speed Settings (50-805 Rpm)
Price:
Get Latest Price
In Stock
Product Specifications
| Dimensions | Variable |
| Features | High Precision, Heavy-Duty, Versatile, Durable, Efficient, Reliable, Powerful, Precise Drilling |
| Material | Steel |
| Motor Power | 2-5 Hp |
| Speed Range | 50-805 Rpm |
| Spindle Taper | Mt-4/Mt-5 |
| Spindle Travel | 150-300Mm |
| Weight | 1750-2900Kg |
Product Overview
Key Features
| Capacity | Model | ||
RD-40 | RD-50 | RD-65 | |
| Max. Drilling Capacity in Steel (M.S) | 40 | 50 | 65 |
| Max. Drilling Capacity in cast iron (C.I) | 46 | 56 | 70 |
| Tapping in Steel | 27 | 42 | 50 |
| SPINDLE | |||
| Spindle Travel | 150 | 250 | 300 |
| Spindle Taper | MT-4 | MT-4 | MT-5 |
| No. of spindle speed (Range) RPM | 9(50-805) | 9(50-805) | 9(50-805) |
| Automatic Feed Valve mm / revolution | 0.115 | 0.115 | 0.115 |
| Optional feed 6 | 0.13-1.10 | 0.13-1.10 | 0.13-1.10 |
| WORKING RANGE | |||
| Column Diameter | 228 | 280 | 330 |
| Max./Min Distance Spindle Centre to Column Centre | 1160 / 550 | 1352 / 615 | 1700 / 700 |
| Horizontal Movement of Drilling Head | 510 | 710 | 1000 |
| Max. / Min Distance Spindle Nose To Base Plate | 1030 / 450 | 1080 /450 | 1120 / 460 |
| Vertical Movement of Radical Arm | 580 | 600 | 660 |
| Working Surface of Box- Table | 560x460 | 560x460 | 560x460 |
| Height of Box table | 400 | 400 | 400 |
| Working Surface of Base Plate | 800 x 670 | 1020 x 800 | 1400 x 850 |
| Height of Base Plate | 170 | 190 | 210 |
| Central | |||
| Drilling Head Motor (H.P / RPM) | 2 / 1440 | 3 / 1440 | 5 / 1440 |
| Elevator Motor (H.P / RPM) | 1 / 1440 | 2 / 1440 | 3 / 1440 |
| Base Plate Dimensions (Length x Wdth) | 1330x820 | 1680x930 | 2050x990 |
| Total height Of Machine (Approx) | 2250 | 2360 | 2440 |
| Wight (Approx) Kg | 1750 | 2350 | 2900 |
Note : We reserve the right to modify the design and specifications without pror notice
