Aemc Instruments 5070 Megohmmeters

The AEMC Instruments 5070 Megohmmeters Model 5070 is a fully automated 5000V graphical insulation tester. Selectable and programmable test voltage (40 to 5100V). Programmable temperature correction of resistance readings. The Model 5070 is the only megohmmeter to offer both a graphical plot of the test right on the instruments, as well as a digital presentation of the test results. It has a large graphic display with five line alphanumeric display and graph. It also offers the ability to program up to three step voltage profiles, each containing up to five steps. The Model 5070 has an RS-232 port which provides the ability to configure the unit and run the test from a PC. Test results can be generated directly to a printer using the DataView graphing and analysis software.

Features :
-True Megohmmeter with selectable test voltage from 40 to 5100V, and fixed test voltages of 500V, 1000V, 2500V and 5000V
-Insulation measurements from 30kO to 10TO
-Automatic step voltage with programmable step and dwell times - three profiles can be stored, each with up to five steps
-Programmable temperature compensation of resistance readings
-Automatic calculation of DAR, PI and DD values
-Direct measurement and display of Resistance, Test Voltage, Run Time, Capacitance and Leakage Current
-Automatic test inhibition if live voltage is present
-Automatic discharge and display of discharge voltage
-128kB memory for storing field test data
