Aaac Conductor - Aluminum Alloy 1350-h-19, High Current Carrying Capacity, Optimal Heat Resistivity Up To 150â°c, Exceptional Durability

Nominal cross-section mm2

Number of structures / diameter n / mm

Outside diameter mm

Calculation section (mm2)

The DC resistance is not greater than (ohm / km)

Calculate the breaking force KN

Calculated mass kg / km

Delivery length of not less than m

aluminum

steel

total

16

3 / 2.60

5.60

6.85

9.08

15.93

3.367

13.32

90.1

2000

16

7 / 1.70

5.10

6.83

9.06

15.89

3.653

12.58

90.0

2000

25

3 / 3.25

7.00

10.7

14.19

24.89

2.327

20.79

140.7

2000

25

7 / 2.15

6.45

10.93

14.48

25.41

2.284

20.12

144.0

2000

35

3 / 3.85

7.54

Lt; / RTI & gt;

19.90

34.92

1.659

29.19

197.5

2000

35

7 / 2.50

7.50

14.77

19.59

34.36

1.689

27.21

194.7

2000

50

3 / 4.60

9.91

21.44

28.42

49.86

1.162

41.68

282.0

1500

50

7 / 3.00

9.00

21.28

28.20

49.48

1.173

39.19

280.4

1500

70

7./3.60

10.80

30.64

40.61

71.25

0.815

56.43

403.7

1250

95

7 / 4.16

12.48

40.91

54.23

95.14

0.610

75.35;

539.1

1000

120

19 / 2.85

14.25

52.12

69.09

121.21

0.481

96.00

689.5

1500

150

19 / 3.15

15.75

63.67

84.40

148.07

0.394

117.27

842.3

1250

185

19 / 3.50

17.50

78.60

104.20

182.80

0.319

144.78

1039.9;

1000

210

19 / 3.75

18.75

90.24

119.61;

209.85

0.278

16.6.20

1193.7

1000

240

19 / 4.00

20.00

102.67

136.09

238.76

0.244

189.10

1358.2

1000

300

37 / 3.20

22.40

127.96

169.61

297.57

0.197

235.68

1702.8

1000

400

37 / 3.70

25.90

171.07

226.76

397.83

0.147

315.08

2276.5

1000

500

37 / 4.16

29.12

216.25

286.65

502.90

0.117

398.30

2877.7

1000

630

61 / 3.63

32.67

271.46

359.84

631.30

0.093

499.99

3637.2

800

800

61 / 4.10

36.90

346.30

459.06

805.36

0.073

637.85

4640.1

800
