5 Mtr Octagonal Pole

5 Meter Octagonal Pole

Pole Height: 5 m
Top Across Flats: 70 mm
Bottom Across Flats: 130 mm
Material: Galvanized Iron (GI)
Wall Thickness: 3 mm
Finish: Hot Dip Galvanized
Arm Type: No Arm
Surface Finish: Polished

Key Features of a 5 Meter Octagonal Pole

Height:

5 meters (approx. 16.4 feet) above ground level.

Shape:

Octagonal cross-section (8-sided), tapered design.
Enhances wind resistance and aesthetic appeal.

Material:

Made from high-quality mild steel sheets (MS).
Conforms to IS:2062 / IS:875 or equivalent standards.

Surface Finish:

Hot-dip galvanized (zinc coating 65a 100 microns) for rust and corrosion protection.
Optional powder coating in various colors for enhanced appearance.

Construction:

Made from a single steel sheet bent and welded to form an octagonal shape.
Precision welded seam with high structural integrity.

Base & Mounting:

Equipped with a flanged base plate for foundation mounting.
Supplied with anchor bolts, nuts, washers, and template for installation.

Bracket & Fixture Compatibility:

Supports various lighting fixtures, including LED and solar street lights.
Provision for single or double arm brackets.

Cable Entry & Access:

Internal wiring path through the pole.
Lockable access door at the base for electrical connections.

Wind Load Capacity:

Engineered to withstand wind speeds of 130a 160 km/h, depending on top load and location.

Applications:

Street & pathway lighting
Parking lots and housing societies
CCTV surveillance poles
Campus or industrial lighting
