3 Core Electric Cable - Color: Black

3 Core Electric Cable Short Specification
4
1. Description

A 3 Core Electric Cable is a power cable consisting of three insulated conductors laid together and covered with an inner sheath and outer protective sheath. It is commonly used for three-phase power supply (without neutral) or single-phase with earth applications.

2. Construction

Conductor: Copper or Aluminum (stranded/solid, Class 1 or Class 2)

Number of Cores: 3

Insulation: PVC / XLPE

Inner Sheath (Bedding): PVC

Armouring (if required): Galvanized Steel Wire/Strip (SWA/STA)

Outer Sheath: PVC / PE (FR, FRLS, LSZH options available)

3. Voltage Rating

0.6/1 kV (standard low-voltage rating)

Higher voltage grades available upon request

4. Standard Sizes

1.5 sq.mm to 400 sq.mm (as per load requirement)

5. Applications

Three-phase motors

Industrial power distribution

Underground cable installations

Control panels

Pumps and heavy-duty equipment

6. Temperature Rating

PVC Insulation: 70C (continuous)

XLPE Insulation: 90C (continuous)
