240w Poly Solar Panels By Sun's Onglory Group Limited

We are offering our client an excellent quality range of 240W Poly Solar Panels. These 240W Poly Solar Panels are made from very high quality raw material which ensures high durability at its user end. These 240W Poly Solar Panels are in high demand in the market. Different sizes and designs are easily available in the market. Our 240W Poly Solar Panels are available at industrial leading prices.
Size and Number of cells 156mmA 156mm 60/6A 10pcs
Maximum Power (Pmax) W 200 205 210 215 220 225 230 235 240
Power Tolerance
Open Circuit Voltage(VOC) V 36.5 36.5 36.5 36.5 37.0 36.5 37.0 37.0 37.0
Short Circuit Current(Isc) A 7.65 7.71 7.88 8.03 8.10 8.17 8.22 8.29 8.33
Maximum Power Voltage(Vmp) V 28.6 28.8 29.0 29.3 29.5 29.6 29.8 30.0 30.2
Maximum Power Current(Imp) A 6.98 7.12 7.24 7.34 7.45 7.60 7.73 7.83 7.95
Max.syst.Oper.voltage V 1000V
Diodes 3 by-pass
Dimension MM 1650x990x50
Weight KG 21
Operate Temp. Scope A C -40/+85
Relative humidity 0 to 100%
Resistances 227g steel ball fall down from 1m height and 60m/s wind
