160w Solar Panel - 36 Nos. Poly Crystalline Cells, 1480 X 665 X 35 Mm Dimensions, Anodized Aluminium Frame, Ip65 Junction Box

Due to our broad knowledge and enormous experience as a this domain we are Manufacturer & Supplier of 160W Solar Panel in Delhi, India.

Technical Specification:

Electrical Parameters at Standard Test Conditions (STC)
ModulesSFTI-160
P max watts nominal160
Voltage at P max VMPP (V)19.01
Current at P max IMPP (A)8.42
Open circuit Voltage Voc (V)22.85
Short Circuit Current Isc (A)8.8
Module Efficiency (%)16.2
Construction Materials
Module Dimension L x W x H1480 x 665 x 35
Weight (kg)11
Junction BoxIP65,3 Terminal with 2 bypass diodes
Application ClassClass A safety class II
Front CoversHigh transmission,low iron,tempered glass
Cells36 Nos. Poly crystalline
Cell EncapsulantEVA (Ethylene Vinyl Acetate)
Back CoverComposite film
FrameAnodized aluminium frame with twin wall profile
Mounting HolesMounting hole 4 nos, oval shape (14 x 7 mm) and 6 mm Grounding hole 2 nos.
