त्रिकोणीय ध्रुवीकरण माइक्रोस्कोप
Price:
नवीनतम कीमत पता करें
Minimum Order Quantity :
1 Unit
Brand Name :
Almicro
स्टॉक में
विस्तृत जानकारी
| थ्योरी | Polarizing microscopy principles for birefringent materials analysis, Polarizing microscopy principles for birefringent materials analysis |
| ड्राट्यूब | Trinocular (360° rotatable, inclined at 30°), Trinocular (360° rotatable, inclined at 30°) |
| सेन्सर | Compatible with external digital camera adapter (not included) |
| रेज़ोल्यूशन | Optical resolution up to 1000x (with 100x objective and 10x eyepiece) |
| अंतरफलक | Photo/Video camera port via trinocular tube |
| फोकल दूरी | 45mm (typical for standard objectives) |
| इज़ाफ़ा | 40x, 100x, 400x, 1000x (with provided objectives and 10x eyepieces) |
| फोकस रेंज | Coarse and fine adjustment; total approx. 30mm |
| ऐपिस | Wide Field 10X (Pair), field of view 18mm |
| ऐपिस ट्यूब | Trinocular, 30° inclined, rotatable |
| रोशनी | Halogen lamp, transmitted polarized light, variable intensity |
| मोटे समायोजन की सीमा | Approx. 20mm travel |
| फाइन एडजस्टमेंट रेंज | Graduation 0.002mm, total 2mm travel |
| काम करने का चरण | Rotatable circular stage, 360°, with vernier scale. |
| इमेज फ़ॉर्मेट | Supports capture via external camera (JPG, PNG, TIFF—depends on camera used) |
| हेड देखें | Trinocular head, 360° rotatable |
| इंटरपुपिलरी दूरी | 55mm to 75mm adjustable |
| ऑब्जेक्टिव अक्रोमेटिक | 4x, 10x, 40x (S), 100x (OIL, S) achromatic objectives, anti-fungal coated, color-coded |
| कंडेंसर | Strain-free, centerable, swing-out type with iris diaphragm |
| प्रकाश स्त्रोत | 6V/20W Halogen with intensity control |
| आयाम | Approx. 230mm×285mm×450mm (L×W×H) |
| फ़्रेम रेट | Up to 60 FPS (with compatible camera, not included) |
| स्टिल इमेज कैप्चर रिज़ॉल्यूशन | Depends on attached camera capability (up to 12MP supported) |
| वीडियो कैप्चर रिज़ॉल्यूशन | 720p, 1080p, or higher with compatible cameras |
| फोकस सिस्टम | Coaxial coarse and fine adjustments, tension adjustable |
| स्पेयर पार्ट्स | Halogen lamp, fuse, immersion oil bottle, dust cover, lens cleaning cloth included |
| विशेषताएँ | Anti-fungal optics, 360° rotatable stage, graduated vernier, built-in polarizer/analyzer, strain-free condenser, trinocular for digital imaging |
| डिलीवरी का समय | 1हफ़्ता |
| आपूर्ति की क्षमता | 10प्रति सप्ताह |
