त्रिकोणीय ध्रुवीकरण माइक्रोस्कोप

त्रिकोणीय ध्रुवीकरण माइक्रोस्कोप

Price:

नवीनतम कीमत पता करें

Brand Name :

Didac

In Stock

स्टॉक में

कंपनी का विवरण

दीदास इंटरनेशनल, 2010 में दिल्ली के नयी दिल्ली में स्थापित, भारत में माइक्रोस्कोप का टॉप निर्माता,आपूर्तिकर्ता है। दीदास इंटरनेशनल ट्रेड इंडिया के सूचीबद्ध उत्पादों के सत्यापित और विश्वसनीय विक्रेताओं में से एक है। आपूर्ति और व्यापार के अपने व्यापक अनुभव के साथ, दीदास इंटरनेशनल ने उच्च गुणवत्ता आदि के साथ बाजार में अपने लिए एक प्रतिष्ठित नाम बनाया है।
ग्राहक केंद्रित दृष्टिकोण पर ध्यान केंद्रित करते हुए, दीदास इंटरनेशनल की अखिल भारतीय उपस्थिति है और पूरे देश में एक विशाल उपभोक्ता आधार को पूरा करता है। दीदास इंटरनेशनल से ट्रेड इंडिया के गुणवत्ता-सुनिश्चित उत्पादों (ध्रुवीकरण माइक्रोस्कोप) को थोक में खरीदें।

व्यापार के प्रकार

निर्माता, आपूर्तिकर्ता

कर्मचारी संख्या

20

स्थापना

2010

कार्य दिवस

से

जीएसटी सं

07DCLPM4529J1Z6

भुगतान का प्रकार

नकद अग्रिम (सीए), अन्य

इस विक्रेता से अधिक उत्पाद

विक्रेता विवरण

GST

जीएसटी सं - 07DCLPM4529J1Z6

नाम

ा. कुमार

पता

रगड़. ऑफिस एड्रेस ५०७ शाहपुरी टावर स ५८ जनकपुरी नयी दिल्ली, दिल्ली, 110058, भारत

गलत विवरण की रिपोर्ट करें

Compare With Similar Products

प्रोडक्ट का नाम

खरीदार प्रतिक्रिया

3

4

4

प्रतिक्रिया की दर

0.96

100.00

मूल्य या मूल्य सीमा

न्यूनतम आदेश मात्रा

10

1 टुकड़ा/टुकड़े

थ्योरी

Polarising light microscopy designed for geological and materials science applications.

ड्राट्यूब

Trinocular (for camera or PC connectivity)

सेन्सर

Not included; compatible with standard digital/CMOS cameras

Not applicable (optical observation)

रेज़ोल्यूशन

Dependent on camera used

Optical resolution up to 1000x, dependent on objective

अंतरफलक

Standard C-mount on trinocular port for imaging equipment

Mechanical tube with accessory port (camera mount optional)

फोकल दूरी

160mm optical system

Standard working distances based on objectives, typically 4-30mm

इज़ाफ़ा

40X to 400X (expandable to 1000X with optional oil immersion objective)

40x, 100x, 400x, 1000x (with standard objectives and eyepieces)

फोकस रेंज

Coarse and fine focusing with anti-backlash mechanism

Coarse and fine adjustments, coarse range 30mm

ऐपिस

Wide field 10X (paired); 16X optional

Wide field 10x/18mm (pair included)

ऐपिस ट्यूब

Inclined at 30° for comfortable viewing

Inclined 30°, 360° rotatable for convenience

रोशनी

Halogen 6V/20W with intensity control; Koehler illumination

Built-in halogen (6V/20W) with field diaphragm

मोटे समायोजन की सीमा

30mm or more

30 mm

फाइन एडजस्टमेंट रेंज

0.002mm per graduation

0.002 mm

काम करने का चरण

Rotatable round stage, 360° graduated, with centering mechanism, 150mm diameter

Circular rotatable polarizing stage with graduation; 120mm diameter

इमेज फ़ॉर्मेट

Dependent on attached camera system

Visual; digital images possible via optional camera mount

हेड देखें

Trinocular, 30° inclined, rotatable 360°

Trinocular, inclined 30°, 360° rotatable

इंटरपुपिलरी दूरी

55mm–75mm adjustable

55-75 mm adjustable

ऑब्जेक्टिव अक्रोमेटिक

4X, 10X, 40X (S); all objectives strain-free polarising type, anti-fungus, DIN standard

Achromatic objectives: 4x, 10x, 40x, 100x (oil)

कंडेंसर

Strain-free Abbe condenser, N.A. 1.25, with iris diaphragm and carrier

Abbe N.A. 1.25 with polarizer

प्रकाश स्त्रोत

Transmitted Halogen lamp, replaceable, adjustable brightness

Halogen 6V/20W, adjustable brightness

आयाम

Approx. 400mm (H) x 220mm (W) x 380mm (D)

Approx. 380mm x 250mm x 400mm

फ़्रेम रेट

Dependent on attached camera

Dependent on camera (not included by default)

स्टिल इमेज कैप्चर रिज़ॉल्यूशन

Dependent on attached camera

Dependent on attachment camera, up to 5MP supported

वीडियो कैप्चर रिज़ॉल्यूशन

Dependent on attached camera

Dependent on camera (optional accessory)

फोकस सिस्टम

Precision rack and pinion, coarse and fine adjustments

Coaxial coarse & fine focusing

स्पेयर पार्ट्स

Halogen lamp, fuse, blue filter, immersion oil, dust cover

Halogen lamp, fuse, eyepieces, objectives, stage clips

विशेषताएँ

Rotatable polariser & analyser, Bertrand lens for conoscopic observation, analyzer slide, quartz wedge and mica plates included

Rotatable analyzer, Bertrand lens, centerable nosepiece, strain-free objectives, graduated rotating stage
