प्रोजेक्शन माइक्रोस्कोप - डूम टाइप (Kw -700c)

प्रोजेक्शन माइक्रोस्कोप - डूम टाइप (Kw -700c)

नवीनतम कीमत पता करें

Minimum Order Quantity :

1 Unit

Brand Name :

Almicro

In Stock

स्टॉक में

विस्‍तृत जानकारी

थ्योरीProjection microscope works by projecting a magnified image of the specimen onto a screen using optical lenses and illumination, suitable for group viewing and educational purposes., Projection microscope works by projecting a magnified image of the specimen onto a screen using optical lenses and illumination, suitable for group viewing and educational purposes.
ड्राट्यूबMonocular, vertical projection tube., Monocular, vertical projection tube.
सेन्सरNot applicable (optical projection system).
रेज़ोल्यूशनDepends on objective lens and screen size; typically up to 1200 lines per inch on screen.
अंतरफलकManual operation, no digital output interface.
फोकल दूरीAdjustable via coarse and fine focusing knobs.
इज़ाफ़ा40X to 400X (standard), extendable to 1000X with additional accessories.
फोकस रेंजCoarse (30mm), Fine (2mm).
ऐपिस10X wide-field eyepiece (viewer for alignment only, not for projection).
ऐपिस ट्यूबVertical tilt, fixed.
रोशनीHalogen lamp 6V/20W (or equivalent), with adjustable brightness.
मोटे समायोजन की सीमा30mm travel.
फाइन एडजस्टमेंट रेंज2mm precision adjustment.
काम करने का चरणRectangular mechanical stage with slide holder, X-Y controls, approx. 120mm x 120mm.
इमेज फ़ॉर्मेटProjected optical image, circular 100mm or larger projection field on screen.
हेड देखेंMonocular, vertical projection with attached projection screen.
इंटरपुपिलरी दूरीNot applicable (projection system).
ऑब्जेक्टिव अक्रोमेटिकAchromatic: 10X, 40X (SL), 100X (oil immersion).
कंडेंसरNA 1.25 Abbe condenser with iris diaphragm and filter holder.
प्रकाश स्त्रोतHalogen bulb 6V/20W with field lens.
आयामApprox. 250mm x 320mm x 500mm (L x W x H).
फ़्रेम रेटNot applicable (static optical projection).
स्टिल इमेज कैप्चर रिज़ॉल्यूशनNot applicable (separate image capture device required).
वीडियो कैप्चर रिज़ॉल्यूशनNot applicable (no built-in video capability).
फोकस सिस्टमCoarse and fine coaxial focusing system.
स्पेयर पार्ट्सExtra halogen lamp, spare fuse, replacement projection screen.
विशेषताएँSuitable for group demonstrations, rugged metal body, built-in projection screen, easy maintenance.
आपूर्ति की क्षमतादसप्रति सप्ताह
डिलीवरी का समयएबीएस प्लास्टिक हफ़्ता

कंपनी का विवरण

कोवा इंटरनेशनल, 1978 में हरियाणा के अंबाला छावनी में स्थापित, भारत में माइक्रोस्कोप का टॉप निर्माता,निर्यातक,आपूर्तिकर्ता है। कोवा इंटरनेशनल ट्रेड इंडिया के सूचीबद्ध उत्पादों के सत्यापित और विश्वसनीय विक्रेताओं में से एक है। आपूर्ति और व्यापार के अपने व्यापक अनुभव के साथ, कोवा इंटरनेशनल ने उच्च गुणवत्ता आदि के साथ बाजार में अपने लिए एक प्रतिष्ठित नाम बनाया है।
ग्राहक केंद्रित दृष्टिकोण पर ध्यान केंद्रित करते हुए, कोवा इंटरनेशनल की अखिल भारतीय उपस्थिति है और पूरे देश में एक विशाल उपभोक्ता आधार को पूरा करता है। कोवा इंटरनेशनल से ट्रेड इंडिया के गुणवत्ता-सुनिश्चित उत्पादों (प्रक्षेपण सूक्ष्मदर्शी) को थोक में खरीदें।

व्यापार के प्रकार

निर्माता, निर्यातक, आपूर्तिकर्ता

कर्मचारी संख्या

40

स्थापना

1978

कार्य दिवस

से

जीएसटी सं

06AAGFK4299P1ZK

संबंधित श्रेणियों का अन्वेषण करें

इस विक्रेता से अधिक उत्पाद

विक्रेता विवरण

GST

जीएसटी सं - 06AAGFK4299P1ZK

4 RatingRating

नाम

मोहित कोहली

पता

४४४ आर्य नगर, जगाधरी रोड, अंबाला छावनी, हरियाणा, 133001, भारत

गलत विवरण की रिपोर्ट करें

Compare With Similar Products

प्रोडक्ट का नाम

खरीदार प्रतिक्रिया

4

3

4

न्यूनतम आदेश मात्रा

1 यूनिट/यूनिट

1

1 टुकड़ा/टुकड़े

थ्योरी

Projection microscope works by projecting a magnified image of the specimen onto a screen using optical lenses and illumination, suitable for group viewing and educational purposes.

वीडियो माइक्रोस्कोप

Drawtube

Monocular, vertical projection tube.

Sensor

Not applicable (optical projection system).

Not applicable (Optical projection system)

Resolution

Depends on objective lens and screen size; typically up to 1200 lines per inch on screen.

Depends on projection optics; typically up to 0.2 micron with standard achromatic objectives

Interface

Manual operation, no digital output interface.

Manual controls; no digital output

Focal Distance

Adjustable via coarse and fine focusing knobs.

Adjustable, typically 45mm

Magnification

40X to 400X (standard), extendable to 1000X with additional accessories.

100x, 200x, 400x, 600x, 1000x (depending on objective and eyepiece combination)

Focus Range

Coarse (30mm), Fine (2mm).

Coarse and fine focus, range up to 20mm total

Eyepieces

10X wide-field eyepiece (viewer for alignment only, not for projection).

Projection eyepiece 10x wide field

Eyepiece Tube

Vertical tilt, fixed.

Inclined monocular projection head (60° inclination)

Illumination

Halogen lamp 6V/20W (or equivalent), with adjustable brightness.

Built-in incandescent lamp with condenser for bright field illumination

Coarse Adjustment Range

30mm travel.

Approximately 30mm

Fine Adjustment Range

2mm precision adjustment.

Approximately 2mm

Working Stage

Rectangular mechanical stage with slide holder, X-Y controls, approx. 120mm x 120mm.

Large mechanical stage with slide clips, stage size approx. 120mm x 120mm

Image Format

Projected optical image, circular 100mm or larger projection field on screen.

Projected optical image; suitable for screen sizes up to 150mm diameter

View Head

Monocular, vertical projection with attached projection screen.

Inclined monocular projection head

Interpupillary Distance

Not applicable (projection system).

Not applicable (monocular head)

Objective Achromatic

Achromatic: 10X, 40X (SL), 100X (oil immersion).

Achromatic objectives 10x, 40x, 100x (oil immersion)

Condenser

NA 1.25 Abbe condenser with iris diaphragm and filter holder.

Abbe condenser with iris diaphragm and filter holder

Light Source

Halogen bulb 6V/20W with field lens.

6V/20W halogen lamp, adjustable intensity

Dimensions

Approx. 250mm x 320mm x 500mm (L x W x H).

Approx. 430mm x 230mm x 210mm (H x W x D)

Frame Rate

Not applicable (static optical projection).

Not applicable (optical projection only)

Still Image Capture Resolution

Not applicable (separate image capture device required).

Not applicable (no camera hardware)

Video Capture Resolution

Not applicable (no built-in video capability).

Not applicable (no camera hardware)

Focus System

Coarse and fine coaxial focusing system.

Coarse and fine coaxial knobs

Spare Parts

Extra halogen lamp, spare fuse, replacement projection screen.

Lamp, fuse, projection bulb, stage clips, objectives, eyepiece

Features

Suitable for group demonstrations, rugged metal body, built-in projection screen, easy maintenance.

Bright and sharp screen image, rugged body, precision focusing, suitable for group viewing and demonstration

आपूर्ति की क्षमता

10 प्रति सप्ताह

10-50 प्रति सप्ताह

डिलीवरी का समय

1 हफ़्ता

1-7 दिन

मूल्य या मूल्य सीमा

नमूना नीति

नमूना लागत, शिपिंग और करों का भुगतान खरीदार द्वारा किया जाना है

मुख्य निर्यात बाजार

एशिया

भुगतान की शर्तें

चेक

नमूना उपलब्ध

1

1

मुख्य घरेलू बाज़ार

ऑल इंडिया
