Weight Indicators - 160x80x125mm Dimensions, 100-240v Power Supply, High-precision Load Cell Indicator With Rs485 Output, Dual Display Design, Supports 4-20ma/0-10v Output

Factory Weighing Controller Alarm Display Device Load Cell Indicator With Rs485 transistor Output
TY5S / A-type five dual-display control instrument
1. Instrument power: 100V-240V AC.
2. Working environment: 0 a -50 a , humidity less than 90% RH, no frost.
3.1 ~ 4 0 ~ 20mV signal input.
4. Sampling speed: 10 times / second, the basic error A 0.03% F.S, display range -19999-99999.
5. With resistance strain gauge load cell, suitable for measurement and control. 5 key operation mode.
6. Output excitation voltage 10V, the current is about 200mA.
7. Total value, net value, peak hold, one-touch zeroing and other functions.
8. High-precision transmission output (4-20mA, 0-5V, 0-10V).
9.4 relay output.
Support RS232 or RS485 communication
11. Support TG ONE data acquisition management software.
12. Dimensions: 160 * 80 * 125, hole size 152 * 76mm.
