Warping Machine - Flange Diameter Up To 1016 Mm, Beaming Width Up To 1384 Mm | Automatic Loading/unloading, Hydraulic Breaking System, Infra Red Sensor, Variable Speed Up To 750 Mtr/min
Price:
Get Latest Price
In Stock
Product Specifications
| Flange Diameter | Up To 1270 Mm |
| Beaming Width | Up To 1600 Mm |
| Cylinder Dryer Diameter | Up To 2134 Mm |
| Drive System | Ac/Dc |
| Breaking System | Hydraulic |
| Machine Speed | 0-750 M/Min |
| Package Size | Up To 330 Mm |
| Features | High Speed, Auto Loading, Precise Tension, Easy Operation, Durable Design, Efficient Drying, Safe Operation, Data Monitoring |
Product Overview
Key Features
Following are the Main Features of Warping Machine :-
Flange Diameter: Up to 1016 mm (40"), Up to 1270 mm (50")
Beaming Width: Up to 1384 mm (54.5"), Up to 1524 mm (60")
Up to 1600 mm (70.8") Other Widths Available
Drying Section:
Cylinders Dryer:
Diameter : 762mm (30"), 812mm (32"), 1372mm (54"), 1600mm (63"), 1700mm (66"), 1830mm (72"), 1981mm (78"), 2032mm, (80"), 2134mm (84"),
Drive: Ac Frequency Converter Drive Or DC
Breaking system: Hydraulic
Features: Automatic Mean Loading/ Unloading Electronic Pre-selection
Counter, Pressure Roll(Rubber)
Accessories: Safely Device
Various Combs
Comb Oscillation
Windscreen
Warp Data Monitoring
Suction And Blower Arrangement
Machine Speed: 0 To 750 Mtr/ Per Min.
Creel:
V Type
Package Size: Up to 254mm (10") Diameter, Up to 330mm (13") Diameter
Stop Motion Drop Wire
Infra Red Non Contact Sensor
Tension system: 3 Rod System.
Flange Diameter: Up to 1016 mm (40"), Up to 1270 mm (50")
Beaming Width: Up to 1384 mm (54.5"), Up to 1524 mm (60")
Up to 1600 mm (70.8") Other Widths Available
Drying Section:
Cylinders Dryer:
Diameter : 762mm (30"), 812mm (32"), 1372mm (54"), 1600mm (63"), 1700mm (66"), 1830mm (72"), 1981mm (78"), 2032mm, (80"), 2134mm (84"),
Drive: Ac Frequency Converter Drive Or DC
Breaking system: Hydraulic
Features: Automatic Mean Loading/ Unloading Electronic Pre-selection
Counter, Pressure Roll(Rubber)
Accessories: Safely Device
Various Combs
Comb Oscillation
Windscreen
Warp Data Monitoring
Suction And Blower Arrangement
Machine Speed: 0 To 750 Mtr/ Per Min.
Creel:
V Type
Package Size: Up to 254mm (10") Diameter, Up to 330mm (13") Diameter
Stop Motion Drop Wire
Infra Red Non Contact Sensor
Tension system: 3 Rod System.
