SP-3015B Digital Profile Projector

Application:

This digital type high-precision projector is a highly efficient measuring instrument integrating light, machine and electricity. It can be widely used for industries such as mold manufacturing, metal work pressing, electronics, instrument, horologe, as well in universities, research institutes and metering examination departments.


Features:

This instrument is a precession measuring device integrating optics, mechanics, electricity and computation into an organic whole; which is widely used in the measuring rooms and workshops of related factories and plants in the sectors of machinery manufacture, instrumentation, clocks and watches and electronics industries. This instrument can easily and speedily check the profiles and surface shapes of various measured parts; e.g., various parts, cutting tools and tools of sample plates, punching pieces, cams, gears, molding milling cutters, tapping tools, etc.



Technical parameters:

Model:SP-3015B (Erect Image)
Projection screen: effective diameter (mm):I 300mm, working scopei I 300 (internally marked with asterisk-shaped line)
Projection screena s rotation angle:: 0i 360A
Resolution of rotation angle: 0.01A or 1a
Accuracy of the rotary angle:6a
Object lensa s magnification:10A i standardi 20A i optionali 50A i optionali 100A i optionali
View-field of object (mm):I 30 I 15 I 6 I 3
Working distance for object (mm):75 69 26 26
Metal stage size:340A 152mm
Glass stage size:190A 75mm
Travela X, Y axis:150A 50mm
Z axis travel:80mm
Resolution of X Y:0.001mm(digital display)
Accuracy:(4+L/25)I m
Stage support:4kg
Data processor:DS-401 or DS600
Ascent and descent mechanism:45 A oblique tooth gear
Profile light source:12V/100W tungsten halogen lamp
surface light source:24V/150W tungsten halogen lamp
Over dimensions:480A 780A 1150mm
Weight:135kg
Power supply:110V/220V (switch) ; 50/60HZ(switch)
Optional accessories:printer , 2D measuring software
