Ts21100 Deep Hole Boring Machine

We are engaged in manufacturing and exporting TS21100 Deep Hole Boring Machine to our clients in Dezhou, Shandong, China. Following Specification: Scope Of Drilling Hole Dia: 60- 150Mm Scope Of Boring Hole Dia : 100- 1000Mm Sleeve Boring Hole Dia 140-500Mm Max Boring Depth : 1-16M Depend On User Request Center Height From Horizontal Rail To Spindle Center 1250Mm Headstock Spindle Hole Dia: 100Mm Front Spindle Taper Hole : 120Mm,1:20 Spindle Rotation Speed, Steps 1-190R/Min 3 Shifts, Stepless Speed Adjust Inside Shift Main Motor : 75Kw Dc Motor Feeding Speed 5-500Mm/Min: Ac Servo Stepless Carriage Fast Moving Speed : 4M/Min Clamping Dia Of Workpiece : 300-1500Mm Drilling Bar Box Spindle Hole Dia : 120Mm Front Spindle Taper Hole Of Drilling Bar Box : 140Mm,1:20 Drilling Bar Box Motor : 45Kw Spindle Rotation Speed, Steps Of Drilling Bar Box : 16-270R/Min 12Steps Feeding Motor : 11Kw Ac Servo Stepless Cooling Pump Motor : 11Kwx4 4Groups Hydraulic Pump Motor : 1.5Kw,N=1440R/Min Rated Pressure Of Cooling System : 2.5Mpa Volume Of Cooling System : 200,400,600,800L/Min Load Bearing Of Machine : 35T One Workpiece Frame 50T Two Workpiece Frames
