Tray Dryer - Triple Walled M.s. Design, 24/48/96/192 Trays | 150a C Temp Range, Microprocessor Pid Control, Air Circulation System

Being a customer centric organization, we are involved in manufacturing and supplying a supreme quality range of Tray Dryer in Mumbai, Maharashtra, India. TRAY DRYER (OUTER & INNER M.S.) : - Construction of Dryer is Triple walled on sides with gap between the walls filled with initial layer of Asbestos Sheets followed by a dense layer of high quality low thermal mass glass wool insulation. - Exterior made of Mild Steel (18 swg.) constructed on thick iron angle framework. The entire outer body is duly painted by long lasting DUCO Paint. - Pre-heating Chamber made of Mild Steel (20 swg.) & Inner Chamber made of Mild Steel 304 grade (18 swg.) - Provision for forced air circulation using motorized blower. - Provided with Control Panel with suitable Indication Lamps for Phase Indication, Heater/Motor On/Off Indication etc. MCB for Mains On/Off and Motor-Blower On/Off Switches. - The unit is incorporated with Microprocessor based Auto tuning type PID Temperature Indicating Controller with Dual Display for Set & Process value indication. - The Controller also has a built-in Digital Timer to set the Soak time if desired in Hours OR Minutes. - A highly accurate Pt-100 3 Wire RTD sensor is used for sensing of Temperature. - DIGITAL HIGH TEMPERATURE SAFETY CUT-OFF INCORPORATED WITHIN THE UNIT. - High quality Nichrome wire Air Heating Elements provided on side walls of the Chamber to maintain temperature uniformity within chamber - Superior quality contactor for cutting / restoring power to the heaters is incorporated. Overload Relays used for motor protection. - Doors incorporated with Safety cut-out system (Limit Switch) which disables the Motor & the Heaters when doors are opened in operational mode. - 24/48/ 96 & 192 Trays Tray Drier Supplied With Heavy Duty (16 swg.) S.S. 304 Pipe Trolley's but without Trays - Electrically operated on 440 V AC 3 Phase Supply. TEMP. RANGE : Ambient + 5A c to + 150A c TEMP. ACCURACY: A 1A c TEMP. UNIFORMITY : A 2A c/A 3A c EXTRAS : CAT.NO. Optional Accessories TAL-1 Aluminium Tray 18 SWG of size 32 x 16 x 1.25 for above Tray Dryers (Each) TSS-304 S.S. (304 grade) Tray 18 SWG of size 32 x 16 x 1.25 for above Tray Dryers (Each) TSS-316 S.S. (316 grade) Tray 18 SWG of size 32 x 16 x 1.25 for above Tray Dryers (Each)
