Threaded Union By Lp Corporation

We are enlisted among one of the veteran manufacturers of Threaded Union. The offered pipe fittings are utilized for combining two pipes together for their diversion or extensions. Engineered and constructed with utmost precision, these products are made from quality certified basic material with modern equipment & tools. Known for high pressure & temperature tolerance capacity and optimum quality, customers can buy these Threaded Union at pocket-friendly prices and in diverse sizes. Technical Specification : Dimensions Of Socket - Weld And Threaded Union (BS3799) (in Mm) Nom. Pipe Size Pipe End Min Socket Bore Dia. Socket Wall Min. Water Way Bore Laying Length Male Flange Min. Nut Min. Threads Per 25.4 Max Bearing Min. Depth of Socket Min. Length Assem. Nominal Clear Assem. Nut A B C D E F G H J K L N 1/8 21.8 10.9210.67 3.17 6.836.43 22.419.0 3.17 3.17 16 1.24 9.6 41.1 49.0 1/4 21.8 14.2213.97 3.30 9.859.45 22.419.0 3.17 3.17 19 1.24 9.6 41.4 49.0 3/8 25.9 17.7817.53 3.48 13.9213.51 26.920.6 3.43 3.43 14 1.37 9.6 46.0 55.0 1/2 31.2 21.8421.59 4.06 17.4717.07 26.920.6 3.68 3.68 14 1.50 9.6 49.0 57.0 3/4 37.1 27.1826.92 4.27 21.7921.39 31.825.4 4.06 4.06 11 1.68 12.7 56.9 67.0 1 45.5 34.0433.78 4.95 28.1427.74 34.326.2 4.57 4.44 11 1.85 12.7 62.0 79.0 1 1/4 54.9 42.6742.42 5.28 35.7635.36 40.632.5 5.33 5.21 11 2.13 12.7 71.1 94.0 1 1/2 61.5 48.7748.51 5.54 41.6141.20 42.234.0 5.84 5.59 10 2.31 12.7 75.5 111.0 2 75.2 61.4761.21 6.05 52.5352.12 45.337.3 6.60 6.35 10 2.69 15.8 86.1 132.0 2 1/2 91.7 74.1773.66 7.65 64.7264.31 61.752.1 7.49 7.11 8 3.07 15.8 102.4 148.0 3 109.2 90.1789.66 8.31 77.6777.27 63.853.6 8.25 8.00 8 3.53 15.8 109.0 175.0 CAUTIONARY NOTE REGARDING HEX HEAD BUSHINGS : Hex head Bushings of one size reduction should not be used in services wherein they might be subject to harmful and forces other than internal pressures.
