Temperature Scanner - Infrared Line Scanner, 1024 Measurement Points | Real-time Thermal Imaging, Ethernet Tcp/ip Communication, Rugged Waterproof Ip65 Enclosure, Air Purge System, Water Cooling For High Temperatures

We are highly popular trader and supplier of Temperature Scanner in New Delhi, Delhi, India. Infrared line scanner is designed for use in highly demanding industrial environments and provides accurate temperature images of moving objects. This multi-point measurement is achieved by a rotating optical system, which collects infrared radiation at up to 1024 points within a 90A field-of-view. The motorized mirror scans at rates up to 150 lines per second. An internal high-speed microprocessor calculates the temperature of the individual measurement points of each line of data. The MP150 includes provision for air or water-cooling, three configurable analog outputs, and two-way digital communications. The line scanner also features on-board Ethernet TCP/IP communication capability and a built-in line laser for rapid alignment.

Highlights:
a c Real-time thermal imaging, scan speed up to 150 Hz
a c Up to 512 measurement points per line
a c Wide choice of spectral and temperature ranges
a c High-quality brushless motor (MTBF 40.000 h)
a c Built-in Ethernet TCP/IP communications
a c RS485 digital communications (up to 1000 m)
a c Three user-configurable 4-20 mA outputs
a c Internal Line Laser for accurate alignment
a c PC independent alarm output
a c Rugged, waterproof IP65 enclosure
a c Air purge keeps window free of dirt and condensation
a c Water cooling for ambient temperatures up to 180A C
