Single Phase Pmdc Drive - 0.14-1 Hp, 0-180v Dc Output | Soft Start, Armature Current Limit, Led Fault Indication, Base Plate Mounting

We are engaged in manufacturing, exporting and supplying excellent quality Single Phase PMDC Drive to our valuable clients in Pune, Maharashtra, India. This compact thyristor controller D.C Drive can work with normal conventional DC motor with permanent magnet DC motors. The speed of DC motor is directly proportional to the armature voltage To vary the speed of a shunt wound seperately excited/PMDC motor the armature voltage has to be varied from zero to the rated voltage of the armature.

LED indication for quick fault finding / status indication
Soft start
Armature current limit / Trip
Fuse Protection
Normal / PMDC motor selection through 1 link
RUN (start) stop.

Specification:
Range : 0.14 HP to 1 HP
Input : Start, Stop, Inch,
Ref : Analog 0-12 V, 4-20 mA (Optional)
Supply : 230 V A 10% 50 Hz
Output : Armature - Variable 0-180V DC<
Armature Current : 4 A Max
Cooling : Natural air Cooling
Dimensions : W : 72mm X H : 72 mm X D : 125mm
Mounting : Base plate mounting (Inside Panel).

Clients can avail this PMDC Drive at industry leading prices from us.
