Siemens Siprotec 6md86 Relay

Get Latest Price

Brand Name :

Siemens

In Stock

Product Specifications

Rated Power	Not Applicable (relay; not power-consuming device)
Output Type	Other, Trip Contacts, Alarm Signal
Phase	Other, Three-phase system (multi-phase busbar protection)
Cooling Method	Natural air cooling
Power Factor	Not Applicable (relay not a load device)
Connector Type	Plug-in terminal blocks
Current Range	Primary and secondary values based on CT ratio, e.g., 1A/5A nominal CT inputs
Power Supply	Auxiliary DC/AC (as per selected variant)
Working Temperature	-10AdegC to +55AdegC (operation)
Noise Level	Silent operation
Application	Busbar protection in HV and MV substations
Rated Current	1 A / 5 A nominal (for CT inputs)
Features	Numerical busbar protection, IEC 61850 communication, high-speed tripping, multi-criteria busbar protection, extensive fault recording
Operating Temperature	-10AdegC to +55AdegC
Product Type	SIPROTEC 6MD86 Numerical Busbar Protection Relay
Output Power	Not Applicable (protective relay)
Output Frequency	Not Applicable (signal, not frequency output)
Input Voltage	DC 24 V, DC 48 V, DC 60 V, DC 110 V, DC 125 V, DC 220 V, AC 100/120/220/230 V (auxiliary supply options depending on variant)
Voltage Protection	Over/Under Voltage Tripping, Differential Protection
Efficiency	High operational reliability
Material	Sheet Steel Enclosure, Flame-retardant plastics
Storage Temperature	-25AdegC to +70AdegC
Weight	Approx. 7 - 12 kg depending on configuration

Product Overview

Key Features
