Pug Type Cutting Machine

Pug Type Cutting Machine

We are engaged in the manufacturing of pug type cutting machine, which is a powerful driven tool used in the cutting of mild steel plate up to 75 mm thick vertical cuts or bevel up to 45 deg. Our range of machines can be made by the following methods:

* Straight line cuts of any length with the machine running on an aluminum track available in length of 1 -8 mtr. and multiples.
* Circle from 75-1140 mm. Diameter when using the circle cutting attachment.
* Freehand cutting simple curves by hand steering (Vertical cuts, only)



The machine mounted STK-3 cutter is designed on the injector suction principle and is suitable for use with acetylene as fuel gas and two seat cutogen nozzles should be used for excellent performance.

Specifications
Cutting Capacity 75 mm. Thick mild steel (approx) Bevel Cutting 50 mm, Thick up to 45 deg. Either side of vertical. Circle from 7 mm-1140 mm. Diameter (approx.)
Cutting Speed Range 19D-83D mm/min At220 volts 1 phase, 5Hz AC Supply
Cutter (STK-3 Injector type) Vertical Adjustment 70 mm. Horizontal Adjustment-90mm. Gas hose connections-1/4" BSP left hand for fuel gas
Input For Drive Motor220/24Q volts, 5QHz. 1 Phase AC for the Fractional horse power geared motor
Additional Accessories If required Circle Cutting Attachment, Cutogen Nozzle 11/16). Cutogen Nozzle (3/64)
