Pneumatic Machine By Shree Chamunda Micro Industries

Pneumatic Machine

TECHNICAL SPECIFICATION

Capacity:- 100 - 500 gm(+/- 2 gm)
Product :- Soji
Sealing Type:- centre Sealing .
Speed :- 20 -30 bags per minute.
Power :- 1/2 HP motor, 220 V, 50 Hz, Single Phase (Compressor power extra ).
Net Weight:- 300 a 330 Kgs. (Approx).
M/c Dimension :- 890 x 760 x 1930 mm (L x W x H) (Approx)..
Packaging material :- All heat sealable laminates film.

FEATURES :

a c Simple operation.
a c Low west Disposal.
a c Easy to change for different pouch size.
a cDigital photo & Temperature controller unit.
a c Fully automatic, Compact and Robust machine.
a cBatch coding device pneumatic ink type.
a cGas flashing unit optional [ extra charge ].
a cWith strip cutting can be adjusted even while the machine is in operation[ 5 a 10- 15 pouches].
a cBag length can be adjusted even while the machine is in operation.
a cControlled by most advanced feather touch key operating panel.
a cCompressor is required.
