Multi Mill - Stainless Steel 304 Beaters, 250 Mm Rotor Diameter, 750-3000 Rpm | Reversible Switch, Easy Dismantle For Cleaning, Continuous Operation, Durable Casters, Flame Proof Option Available

Our Multi Mill is widely used for wet and dry granulation, pulverisation etc., in Pharmaceuticals, Chemicals, Cosmetics, Ceramics, Colours, Dyestuff, Food products etc. It also finds application in Pesticides, Fertilizers, Spices, Detergents, Insecticides, Plastics and Resins Industries. Our Multi Mills are available at industrial leading price. Salient Features of Multi Mill: * Direction of beaters can be changed by reversible switch from knife to impact forward and vice-versa * All contact parts can be easily and quickly dismantled and cleaned * Machine is designed for continuous operation * Cylindrical screen for higher output * Castors provided for mobility * Flame proof Electricals can be provided at extra cost. * Beaters and scrapper blades of SS 304 quality. Technical Specifications of Multi Mill: Out Put : 50 kg to 200 kg/hour depending upon the product and the reduction required in size. Rotor assembly dia : 250 mm (approx.) Rotor speed : 750/ 1500/ 2300 /3000RPM. Beaters : 12 nos. with knife and impact edges.and 2 scraper blades Screen Dimension : Dia. (ID) 260 mm. Ht. 135 mm. Motor : TEFC, 3 HP/1440 RPM/ 440 V/50CS/ 3PH/ AC Starter : DOL with reversible switch. Material charging ht. : 1445 mm (approx.) Overall Dimensions : 870 x 965 x 1630 mm Ht. Net Weight : 275 kgs. (approx.) Gross weight : 425 kgs. (approx.) Case Dimensions : 1200x1550x1860 mm (HT)
