Labex Microscope

Digital Research Microscopy

• Infinity Optical System
• C shape corrosion resistant stand with convenient location of focus controls, Anti Fungus Treated
• Siedentopf Trinocular tube, 30 inclined, 360 rotatable, IPD 54-75mm with in-built 5.0 Mega Pixel
• Wide Field eyepiece WF 10x/20mm paired with Dipoter Adjustment & eye guards
• Quadruple Reverse angle Nosepiece (Ball bearing type)
• IP series DIN Infinity Plan Achromatic objectives 4x, 10x, 40x(SL) and 100x (SL, Oil) Co-axial coarse and fine focusing mechanism with tension control stage rectangular size 140 x 132mm double plate with mechanical stage cross travel 75 x 50mm on ball bearing with co-axial control, Spring clip Double Slide Holder
• Sub-stage ABBE condenser NA 1.25 with aspheric lens. Iris diaphragm and special day light blue filter Koehler Illumination system Super Bright White LED with intensity control
• Image Sensor: 1/ 2.5CMOS, Valid Pixel: 2592x1944. Digital Output: 24-bit(color) Image Format 2592x1944 2.5f/s, 1024x768 10f/s frame rate Sensitivity: 550um/lux/s, . Image Output: USB2.0 Directshow and Twain Windows System: Windows 2000 XP/Vista/Win 7 32bit or 64 bit Image Analysis & Measurement Software dgsoft ProMED^TM version 5.06 for image capturing processing Measurement Image amalgamation. Features include Image editing,View Image Processing Filters, Custom Reports, Capturing etc
• Optional Accessories: Phase Contrast Kit, Dark Field kit, Polarizing kit, Dark Field Kit, Fluorescence attachment, Green Filter.
