Laboratory Test Chambers
Price:
Get Latest Price
Minimum Order Quantity :
1
In Stock
Product Specifications
| Temp Range | 20 C to 60 C |
| Temp Accuracy | 0.2 C |
| Temp Uniformity | 1 C |
| Humidity Range | 40% to 90% |
| Humidity Accuracy | + 2 % |
| Humidity Uniformity | + 3 % |
| Construction | Double walled |
| Features | Accurate dimension, Long life, Best quality, Corrosion resistant, Abrasion resistant |
| Payment Terms | Cheque, Telegraphic Transfer (T/T), Others, Cash in Advance (CID), Cash Advance (CA) |
| Packaging Details | As per requirement |
| Main Export Market(s) | Australia, North America, Eastern Europe, Middle East, Western Europe, Africa, Central America, South America, Asia |
| Main Domestic Market | All India |
| Certifications | ISO 9001:2008 |
Product Overview
Key Features
- Dimensionally accurate
- Long service life
- Best quality
- Corrosion resistant
- Abrasion resistant
Technical Specification
- Temp. Range : 20C to 60C
- Temp. Accuracy : 0.2C
- Temp. Uniformity : 1C
- Humidity Range : 40% Rh to 90% Rh
- Humidity Accuracy : + 2 % Rh
- Humidity Uniformity : + 3 % Rh
- At 25C : RH = 60%
- At 30C : RH = 65%
- At 40C : RH = 75%
| Standard Model (S) | Inside S.S. 304 with mirror polish & outside mild steel powder coated. |
| GMP Model (G) | Inside S.S. 316 with mirror polish & outside stainless steel 304 with dull buff finish. |
Specification
- Double walled construction with backside triple.
- 3 Thick PUF Insulation ensures stable temperature with humidity & reduced energy consumption.
- Motorized Blower at back side of the chamber develops unique air flow system which ensures maximum uniform temperature & humidity condition inside the chamber.Unique air flow assures quick recovery after door openings.
- 1/12 HP, TEFC , F-class insulation, Single phase, 1440 RPM, 230 Volts
- High quality U shape S.S. Tubular Heaters are used for better heating.
- Steam injection system (Non condensing type) & reservoir tank with water level arrangement with indicator.
- Temperature Control : By means of Imported Microprocessor based auto tuned PID controller with CE mark & dual display of set value & process value.
- Humidity Control & Sensing : By means of Imported Microprocessor based auto tuned PID controller with CE mark & dual display of set value & process value with direct % RH.Direct RH electronic capacitor type humidity sensor, avoid wick cup & water.
- Additional Safety thermostat to cut of dry heater supply in case temperature of overshoot.
- Float switch to cutoff the wet heater supply in case of low water level. Audio & Visual alarm.
- Compressor ON delay timer (2 min.) to safe guard the compressor.
- In built over load protector provided for hermetically sealed compressor.
- Refrigeration by means of CFC Free hermitically sealed Emerson Copland make compressor with R 134A for better cooling with ECO friendly refrigerant with time delay to safe guard compressor system.
- 50 mm validation port hole with silicon rubber seal to insert sensors for validation.
- Full view observation Acrylic door with gasket to observe sample inside the chamber.
- Interior illumination for Working area
- Specially designed stainless steel rod trays ensure uniform temperature distribution.
| Models | Capacity | Internal size | External Size | Trays |
| TI 710 S / G | 100 | 50 x 50 x 40 | 113 x 71 x 98 | 2 |
| TI 711 S / G | 170 | 70 x 60 x 40 | 133 x 81 x 98 | 2 |
| TI 712 S / G | 200 | 60 x 60 x 60 | 123 x 81 x 118 | 2 |
| TI 713 S / G | 285 | 80 x 60 x 60 | 146 x 81 x 118 | 3 |
| TI 714 S / G | 325 | 90 x 60 x 60 | 156 x 81 x 118 | 4 |
| TI 715 S / G | 400 | 110 x 60 x 60 | 176 x 81 x 118 | 4 |
| TI 716 S / G | 600 | 125 x 70 x 70 | 191 x 91 x 128 | 4 |
| TI 717 S / G | 800 | 125 x 80 x 80 | 193 x 101 x 138 | 5 |
| TI 718 S / G | 1000 | 157 x 80 x 80 | 225 x 101 x 138 | 5 |
| TI 719 S / G | 1500 | 146 x 150 x 69 | 214 x 171 x 127 | 10 |
| TI 720 S / G | 2000 | 146 x 150 x 92 | 214 x 171 x 150 | 10 |
Note: Two blowers for 400 ltrs to 2000 ltrs. Capacity chambers.
OPTIONAL FEATURES
- PLCfor auto change over for standby refrigeration system with HMI
- CFR 21 part 11 compliance software for PLC with RS 485 or Ethernet communication
- Stand by refrigeration and humidity system
- Data Logger
- CFR 21 part 11 compliance software for data logger
- Data scanner complete with sensor
- SMS Mobile alert system
- Door access security system
- Safety digital temperature controller
- Timer
