Ic Tps54331dr Application: Cycle By Cycle Current Limit

The TPS54331 is a 28-V, 3-A non-synchronous buck converter that integrates a low Rds(on) high side MOSFET. To increase efficiency at light loads, a pulse skipping Eco-modea c feature is automatically activated. Furthermore, the 1 AuA shutdown supply current allows the device to be used in battery powered applications. Current mode control with internal slope compensation simplifies the external compensation calculations and reduces component count while allowing the use of ceramic output capacitors. A resistor divider programs the hysteresis of the input under-voltage lockout. An overvoltage transient protection circuit limits voltage overshoots during startup and transient conditions. A cycle by cycle current limit scheme, frequency fold back and thermal shutdown protect the device and the load in the event of an overload condition.
