Gcc Ar-24 Cutting Plotter Machine

Power consumption : 65.5 Watts Mechanical resolution : 0.012 mm Cache Capacity : 32 MB Cutting Width : 305 mm Cutting Length : Up to 1000 mm Operational Method : Roller-Type Max Cutting Width : 600mm (23.6") Max Cutting Length : 50m (164'''') Max Media Loading Width : 71.9cm (28.3") Number of Pinch Rollers : 3 Acceptable Material Thickness : 0.8mm (0.03") Drive Motor : Stepper motor Max Cutting Force : 250 g Max Cutting Speed : 552 mm /sec (21.7 ips) (at 45 Deg. direction) Offset : 0~1.0 mm (with an increase of 0.025mm) Memory Buffer : 32 MB Interfaces : USB 2.0 (Full Speed), Serial (RS-232C) Type of Command : HP-GL, HP-GL/2 Software Resolution : 0.025 mm Distance Accuracy : (-+)0.254 mm or (-+)0.1% of move, whichever is greater Repeatability : (-+)0.1mm Guaranteed Tracking : 1M Curve and Arc Smoothing : Yes Configurable Origin : Yes Test Cut capability : Yes Diameter of Blade : 2.5 mm Repeat : Yes Control Keys : 10 Control keys and 2 LED Power Supply : AC adapter, 24V DC (1.67A) Operation Temperature : 15~30 Deg. Cel Operation Humidity : 25%~75%
