Fully Automatic Vibro Press Brick And Block Machine Htc-1034-12 - Capacity: 18000 Pcs/hr
Price: 4474560.00 INR / Set
(3792000.00 INR + 18% GST)
Get Latest Price
MRP:
4474560.00 INR / Unit
Weight :
12.00 Tonne
1 Pack Contains :
1
Minimum Pack Size :
1
In Stock
Product Specifications
| Color | white blue |
| Product Type | Concrete Block and Bricks |
| General Use | Concrete Block Making Machine |
| Material | Concrete |
| Capacity | 18000 Pcs/hr |
| Weight (kg) | 14 Tonne |
| Computerized | Yes |
| Automatic | Yes |
| PLC Control | Yes |
| Method | Other |
| Vibration Type | Mold Vibration |
| Vibration Frequency | 35 Hertz (HZ) |
| Maximum Pressure | 220 Bar |
| Machine Power | 61 Horsepower (HP) |
| Voltage | 440 Volt (v) |
| Dimension (L*W*H) | 400x200x200 Millimeter (mm) |
| Pallet Size | 34aEUR x 24aEUR x 24mm |
| Minimum Height | 11 Foot (ft) |
| Maximum Height | 13 Foot (ft) |
| Number of Bricks | 12 |
| Feature | Fire Resistant, High Durability, Low Weight |
| Warranty | 1 Year |
| Payment Terms | Cash Advance (CA), Cheque, Cash on Delivery (COD) |
| Supply Ability | 2 Per Month |
| Delivery Time | 30 Days |
| Sample Available | No |
| Packaging Details | Loose |
| Main Export Market(s) | Asia, Africa |
| Main Domestic Market | All India |
| Certifications | An ISO 9001:2015 Certified Company |
| Pkg Box Height | 168.00 in |
| Pkg Box Breadth | 90.00 in |
| Product Unit | 1 Unit/Units |
| Stock Quantity | 5 |
| Shipping Type | free |
| Pkg Box Length | 480.00 in |
| Currency | INR |
| MRP | 4474560.00 INR |
| Unit Type | Unit/Units |
| Returnable | No |
| Color | white blue |
| Price | 3792000.00 INR (Approx.) |
| Price Type | fixed |
| GSTIN | 18% |
| Brand Name | Build Con |
| Weight | 12.00 Tonne |
| Mop | 1 |
| Moq | 1 |
| Packsize | 1 |
| Minimum Ordered Packs | 1 |
| Minimum Order Quantity | 1 |
Product Overview
Key Features
2.Oil Tank Capacity: 400 Liter, Standard Company, Grade 68 No. Hydraulic Oil.
3.Production Capacity per Shift 8 Hour: Color Paver- 6000 to 7000, Solid & Hollow Block- 2500 to 3000, Bricks- 12000 to 12500.
4.Paver Block per Stock: 6 Block or depend on design (Design as per requirement).
5.Solid & Hollow Block per Stock: 2 or 3 Block depend on size (Size As per requirement).
6.Bricks per Stock: 8 Bricks 230 X 110 X 75mm or as per requirement.
7.Mould Vibro System: 10 HP.
8.Pallet Forward System: 1 HP.
9.System Vibro, Oil Chiller, Pallet Auto Cut, Varam System, Magnetic System, Special Oil Filter, Feeding & Mould Gap Adjustable Plate, etca
10.Auto Color Feeding: Auto Double Feeder Attachment for Top Layer, Color Paver.
11.Pan Mixer: 6 Ft. 600 Kg Capacity, Heavy Duty, Roller & Blade, Powerful Worm Reduction Gear Box Transmission Unit.
12.Conveyor: Ft 30 X Width 18 Inch X Thickness 8mm (Dunlop or MRF Belt).
13.Color Mixer (Drum Type): Color Mixing for Top Layer of Paver Blocks.
14.Auto PLC: Fully Auto PLC operating all system & Warranted safety system with HMI Display.
15.Auto Pallet Stacker: (Gear Type) For Shifting & Arranging Green Bricks Pallet from Press to pallet Truck or Stacker System (If require).
16.Note: Specifications are subject to change for improvement, Engineering drawing for civil work and shed for the machine installation.
