Four Side Moulder By Kalyan Industries

FOUR SIDE MOULDER - 5 HEAD (TAIWAN MAKE)
MODEL KI-BL5-23 (HEAVY DUTY)
Complete with following features : -
Size 230mm (width) x 125 mm (thickness).
Hard Chromed Table
Without Cutter Head
Required motors & electric panel.

Specifications :
Model KI-BL5-23 (HEAVY DUTY)
CapacityMoulding Spindle Number5
Working Width 18-230 mm
Working Thickness 6-125 mm
Min. Working Length 200 mm
Feed Speed 7-28 m/min
Motor1st Bottom Horizontal Spindle 7.5 HP
2nd Right Vertical Spindle 7.5 HP
3rd Left Vertical Spindle 10 HP
Top Horizontal Spindle 10 HP
Bottom Horizontal Spindle 10 HP
Feed 5 HP
Elevation 3/4 HP
Cutting Circles First Bottom Horizontal Spindle 100~i 200 mm
Right Vertical Spindle 110~i 180 mm
Left Vertical Spindle 110~i 200 mm
Top Horizontal Spindle 110~i 200 mm
Second Bottom Horizontal Spindle 100~i 180 mm
Spindle Spindle Diameter 40 mm
Spindle Cutting Speed 6200 RPM (50 HZ)
Adjustment range of Vertical Spindle 45 mm
Adjustment range of Horizontal Spindle 35 mm
All otherDust Outlet Diameter 150 mm
Infeed Table 2 m
Feed Roller Diameter 140 mm
Feed Roller Width 2A 50 mm
Pneumatic Pressure for Feed Rollers, Max 6 bar (87 psi)
Adjustment range for infeed 10mm
table and edge - jointing fence
Sequence B-R-L-T-B
Packing Dimensions (LA WA H) 354A 201A 211 cm
Net Weight 3500 kgs.
Gross Weight 4000 kgs.
Specifications may be changed or modified without notice.
