Esko Cdi Spark 2530 - External Drum Design, Max Plate Size 25" X 30", 1000 Kg Weight, High Power Fiber Laser Source, Up To 4000 Ppi Resolution, Efficient Imaging Time 39 Min

Brand : Esko
Weight : 1000 Kg
Machine Depth : 870 mm (loading table closed), 1180 mm (loading table open)
Machine Height : 1070 mm
Max Plate Size : 635 x 762 mm
Imaging Time : 39 min Optics 7.5 (0.75m2/h)
Model No : CDI Spark 2530
Machine Width : 1600 mm

Type of imager
External drum design
Drum size: max. plate format 25a
x 30a / 635 mm x 762 mm or
smaller
Solid granite machine base
High power Fiber Laser source,
Class 1 laser

Image quality
Screen rulings: up to 200 lpi,
depending on imaging resolution
Halftone 1-99%
Resolutions: fully variable from
2000 to 4000 ppi on job-to-job base

Engine control
GrapholasAR on Intel PC with Windows 2000.
The input file format is LEN or
TIFF, compatible with all CDI family members.

RIP SW & input format
Optional FlexRip 2530
AdobeAR-certified PostScript/PDF input channel with Esko screens (circular, square round, elliptical)
Additional Esko screens and proofing modules available

Plates
All digital photopolymer plates or ablative film
Usable plate thickness: 0.030a to 0.255a / 0.76 mm to 6.35 mm
Sizes up to: 25a x 30a / 635 mm x 762 mm (or smaller)

Letterpress option available
For steel-base Letterpress plates (sizes up to 635 x 815 mm)
Magnetic drum with customized register pin system for digital steel-base Letterpress plates
Magnetic-vacuum drum for all digital polyester-base plates and steel-base Letterpress plates

Installation requirements
Separate vacuum and exhaust system included
No external compressed air supply needed
No external water cooling is required
Electrical: 230V/N/PE, 50/60 Hz, 1.9 kVA (imager) 230V/N/PE, 50/60 Hz, 1.2 kVA (exhaust unit)
