Ferro Alloy Batching System

We are renowned manufacturer, supplier and exporter of Ferro Alloy Batching System in Pune, Maharashtra, India available with following details: Specifications: Weighing and Batching operation: Raw material from ground hopper is discharged on a conveyor than reversible conveyor located on top of day bunkers. As per requirement reversible conveyor will discharge the material on two shuttle conveyors to fill up day bunkers. 12 day bunkers are provided for 12 different raw materials. Vibrating feeders are provided below 12 number of day bunkers in coarse and fine mode. 3 weigh hoppers below 12 number of day bunkers. Each weigh hopper is installed on 3 or 4 Nos. of suitable capacity imported Load cells to get Weight Indication on batch controller, Batch controller will process the signal of 4-20mA and is provided to PLC for automation, Batch conveyor will carry & discharge the batched materials on the furnace charging conveyer. Auto Mode: PLC programming is done as per the composition of batching operation to have a flexibility in selecting random component recipe. The PLC, SCADA is integrated with program Total plant batching operations can be monitored from the PC screen with required reports. Semi Auto Mode: The Batch controllers having facility to program for individual set points timers, discharge, manual component, etc, inputs, outputs. Batch house panel will have Mimic diagram of the complete Batch system to know the status of the field Instruments.
