Engine Oil Pressure Sensor - 6.5psia To 106.5psia Pressure Range | Linear Amplified Output, Temperature Compensated, Superior Long-term Stability, Low Power Consumption, Wide Operating Temperature -40c To +125c

Our company is pioneer in manufacturing and exporting an extensive array of Engine Oil Pressure Sensor in Shenzhen, Guangdong, China. Engine Oil Pressure Sensor is designed for Engine lubrication system oil pressure measurement, available for a broad range of process media including hydrocarbon based fluids, air, and gases. External Hex threads M14X1.5 pressure connection, PWM or Voltage output optional. Features: A. Linear Amplified Output. A. Temperature Compensated. A. Superior Long-Term Stability. A. Low Power Consumption. A. Wide operating temperature range -40C to +125C. A. Good measuring medium compatibility, available for liquid and gas press medium. A. External Hex threads M14X1.5 for easy pressure connection. A. Optional for PWM or Voltage output. Applications: A.Engine lubrication system oil pressure measurement. A.Oil & Fuel Pressure. A.Compressor Control. A.HVAC/R Equipment. A.Industrial Engines. A.Air Pressure. A.Home appliance. Technical Specification: Pressure range 6.5psiA-106.5psiA Max pressure 160psiA Burst Pressure:213psiA Operating temperature -40i +125a Medium: PAG oil, air Supply voltage: 5VDC Nominal Output Voltage: 0.5-- 4.5VDC Accuracy: +/-3%FSi +/-2%(preset area)
