Digital Temperature Indicator By Expert Vacuum Systems Llp

Digital Temperature Indicator is manufactured by our experienced professionals using sophisticated techniques and premium quality raw materials in tandem with defined norms. As an outcome, it is known for high performance, noted operations, longer functional life and accurate measurement. In addition, in order to suit the different requirements of the domain, we offer Digital Temperature Indicator at pocket friendly prices. Hence, we are appreciated as a leading Manufacturer and Supplier of the domain. Salient features of the provided product are as follows:

• Highly accurate and stable display
• Bright red LED display

• Full 4 digit display
• Quality assured

LED Display

Expert Systems manufacturers of electronic process control instrument such as digital temperature indicator and controller. Temperature is an important variable in manufacturing, quality control, and maintenance
processes. Monitoring temperature insures that processes are operating consistently under optimum conditions which results in improved product quality, increased productivity, and reduced down time.

Technical data

Display	Digit 7 Segment Red LED of 0.5” Ht
Resolution	1°C (0.1°C Optional In Case Of Input Sensor RTD PT-100.)
Sensor Input	J, K, R, S, T TYPE T/C or RTD PT-100 MV, 4-20 MA I/P
Indication Accuracy	J ,K ± 1% , R,S ± 0.5 %, RTD ± 0.5 %, mV, mA ± 0.2 %
No. of Input sensor	1 For Single Channel Indicator, 6 / 12 For Multi Channel Indicators
Supply	230 V AC 50 Hz ( 110 V Ac Optional) ±10%
Enclosure	ABS plastic
Front Fascia	ABS plastic with polycarbonate graphics
Sizes in mm	48 x 96 mm., 96 x 96 mm
Panel Cutout	42 x 92 mm., 92 x 92 mm

 Features:

• Accepts Linear & Non-Linear inputs
• Highly accurate and stable display
• Bright red LED display 0.5"
• Micro controller based
• Full 4digit display
• Housing for protection in corrosive and hazardous atmosphere
